Cisco UCS Server Configuration Utility, Release 5.0
Chapter 3 Understanding UCS Server Configuration Utility User Interface
UCS-SCU GUI Home Page
Navigation Pane
Table 3-2 describes the elements in the Navigation Pane.
Toolbar Pane
Table 3-3 lists and describes all the UCS-SCU icons that you can use to perform specific tasks.
Table 3-2 Navigation Pane Elements
Element Description
Server Inventory Displays the server information and inventory.
Contains links to the following pages:
• Server Information
• Inventory
For more information about Server Inventory, go to Chapter 4,
“Viewing Server Inventory.”
Server Health Displays the health of the subsystems on your server such as
CPUs, memory, power supplies, fans, storage, PCI devices,
BIOS, and CMC.
For more information about Server Health, go to Chapter 5,
“Viewing Server Health”
Server Configuration Configures a RAID volume on attached hard drives of your
server.
Contains links to the RAID configuration pages:
For more information about Server Configuration, go to
Chapter 7, “Configuring RAID Levels”
OS Install Installs the RHEL, SLES, Windows, and ESXi operating
systems in a fully unattended mode. The most recent drivers
for all onboard components are added from the Tools and
Drivers CD or from other supported locations during the
operating system installation.
For more information about OS Install, go to Chapter 6,
“Installing Operating Systems”
Table 3-3 Toolbar Elements
Toolbar Icon Name Function
Network Configuration Configures the IP address, DNS and
Subnet mask, and Cisco.com credentials.
Probe Server Performs health check.
To Next Page
