Chapter 3 Installing the Voice Gateway
Mounting the Chassis onto a Wall
Procedure
Step 1 Secure two screws 5 7/16 in (13.81 cm) apart into a wall and 5/32 in (0.40 cm) out from the wall.
Step 2 Hang the chassis on the screws as shown in Figure 3-3.
Figure 3-3 Mounting the Cisco VG202, Cisco VG202XM, Cisco VG204, or Cisco VG204XM Voice
Gateway Chassis onto a Wall
231985
1
5
6
4
2
7
3
