Catalyst 2900 Series XL and Catalyst 3500 SeriesXL Software Configuration Guide

78-6511-08

Chapter 1 Overview

Network Configuration Examples

Figure 1-3 Collapsed Backbone and Switch Cluster Configuration

IP IP IP

Catalyst 3550-12G switch

200 Mbps

Fast EtherChannel

(400 Mbps full duplex

Fast EtherChannel)

Gigabit

servers

Cisco

CallManager

67974

Cisco 2600 router

1 Gbps

(2 Gbps full duplex)

Cisco

IP Phones

Cisco IP Phones

Workstations running

Cisco SoftPhone software

Catalyst

2900 XL,

1900, and

2820 cluster

Catalyst

3524-PWR XL

GigaStack cluster

Catalyst

2900 XL and 3500 XL

GigaStack cluster

power

source

Default Chapter4
