251
Minimum
software
Cisco NX-OS Release
4.0(1A)N2(1) (Nexus 5000
Series)
• Cisco NX-OS
Release 4.2(1)N2(1)
(Nexus 5000 Series)
• Cisco NX-OS
Release 5.2 on the
Cisco Nexus 7000
Series
• Cisco NX-OS
Release 4.2 (Nexus
5000 Series)
• Cisco NX-OS
Release 5.1 (Nexus
7000 Series)
Cisco NX-OS
Release 5.1(3)N(1)1
(Nexus 5000 Series)
Cisco Nexus 2000 Series Gigabit Ethernet Fabric Extenders Environment
Dimensions
(height x width x
depth)
1.72 x 17.3 x 20.0 in. (4.37 x
43.94 x 50.8 cm)
• 1.72 x 17.3 x 17.7 in.
• (4.37 x 43.94 x 44.96
cm)
1.72 x 17.3 x 17.7 in.
(4.37 x 43.94 x 44.96
cm)
1.72 x 17.3 x 17.7 in.
(4.37 x 43.94 x 44.96
cm)
Weight • 18 lb (8.2 kg)
• *Systems are fully loaded
with two power supplies
and one fan tray
• 16.6 lb (7.53 kg)
• * Systems are fully
loaded with two
power supplies and
one fan tray
• 17.7 lb (8.0 kg)
• * Systems are fully
loaded with two
power supplies and
one fan tray
• 17.7 lb (8.0 kg)
• * Systems are fully
loaded with two
power supplies
and one fan tray
Indicator and
port specification
• System status: green (operational), amber (fault), flashing amber (POST boot up), off (no power)
• Locator LED: bright blue locator
• Port status: green (link established), amber (administratively disabled), flashing amber (fault)
• Fan status: green (operational), amber (fault)
• Power status: green (operational), amber (fault)
Environment • Operating temperature: 32 to 104°F (0 to 40°C)
• Nonoperating temperature: -4 to 158°F (-20 to 70°C)
• Humidity: 5 to 95 percent (noncondensing)
• Altitude: 0 to 10,000 ft (0 to 3000m)
Power supply N2K-PAC-200W N2200-PAC-400W,
N2200-PAC-400W-B,
and N2200-PDC-
400W
N2200-PAC-400W,
N2200-PAC-400W-B,
and N2200-PDC-
400W
N2200-PAC-400W,
N2200-PAC-
400W-B, and
N2200-PDC-400W
Fan tray N2K-C2148-FAN N2K-C2248-FAN and
N2K-C2248-FAN-B
N2K-C2248-FAN and
N2K-C2248-FAN-B
N2K-C2248-FAN
and N2K-C2248-
FAN-B
Typical input
operating power
150W (Max 165W) 80W (Max 95W) 95W (Max 110W) 95W (Max 110W)
Input current • 1.5A/2.2A (typical/
maximum)
• Note: Input currents listed
for 110V; divide by 2 for
220V
• Supply will surge on AC
power-up for a fraction
of a second beyond this
rating
• 0.75A/0.90A
(typical/maximum)
• Note: Input currents
listed for 110V;
divide by 2 for 220V
• Supply will surge on
AC power-up for a
fraction of a second
beyond this rating
• 1.0A/1.2A (typical/
maximum)
• Note: Input currents
listed for 110V;
divide by 2 for
220V
• Supply will surge
on AC power-up
for a fraction of a
second beyond
this rating
• 1.0A/1.2A (typical/
maximum)
• Note: Input
currents listed for
110V; divide by 2
for 220V
• Supply will surge
on AC power-up
for a fraction of a
second beyond
this rating
Output current 11.5A/16.7A (typical/
maximum)
5A/7A (typical/
maximum)
8A/10A (typical/
maximum)
8A/10A (typical/
maximum)
Heat dissipation 670 BTU/hr 201/282 BTU/hour
(typical/maximum)
322/403 BTU/hour
(typical/maximum)
322/403 BTU/hour
(typical/maximum)
