Hardware Features: Nexus 4000 Series
N4K-4001I-XPX
Switching Fabric (Gbps) 400
Packets per Second (Mpps) 300
MAC Addresses Supported 8192
Latency (microseconds) 1.5
Maximum Transfer Unit (bytes) 9216 (jumbo frames)
Number of Configurable VLANs 512 (configurable range 1 to 4096)
Onboard Memory 2-GB DDR2 DIMM with ECC
Flash Memory 1-GB eUSB
Hardware Queues per Port 8
1 or 10 GBE Server Facing Ports 14
1 or 10 GBE Uplinks 10
10/100/1000 Management Ports 2
Maximum Watt Power Consumption 12V at 5.75A (69W)
AC/DC Support AC Only
Redundant Power Supply Support No
Dimensions (L x W x H) Inches 10.27 x 11.57 x 0.79
Dimensions (L x W x H) Millimeters 260.93 x 293.9 x 20
Unit Weight Pounds (Kilograms) 3.94 (1.79)
Predicted Mean Time Between Failures (MTBF) Approx. 187,265 hours
