DETAILED STEPS
Configuration Examples for Implementing Multicast Routing on
Cisco
IOS XR Software
This section provides the following configuration examples:
• MSDP Anycast RP Configuration on Cisco IOS XR Software: Example, page MCC-64
• Bidir-PIM Configuration on Cisco IOS XR Software: Example, page MCC-66
• Calculating Rates per Route: Example, page MCC-66
• Preventing Auto-RP Messages from Being Forwarded on Cisco IOS XR Software: Example,
page MCC-67
• Inheritance in MSDP on Cisco IOS XR Software: Example, page MCC-68
• Configuring IPv4 Multicast VPN: Example, page MCC-69
• Configuring IPv6 Multicast VPN on the Cisco XR 12000 Series Router: Example, page MCC-79
• Configuring Multitopology Routing: Example, page MCC-90
• Configuring MVPN Extranet Routing: Example, page MCC-91
MSDP Anycast RP Configuration on Cisco IOS XR Software: Example
Anycast RP allows two or more rendezvous points (RPs) to share the load for source registration and to
act as hot backup routers for each other. MSDP is the key protocol that makes Anycast RP possible.
Command or Action Purpose
Step 1
configure
Example:
RP/0/RP0/CPU0:router# configure
Enters global configuration mode.
Step 2
router pim
RP/0/RP0/CPU0:router(config)# router pim
Enters the PIM configuration mode.
Step 3
mofrr rib acl-name
Example:
RP/0/RP0/CPU0:router(pim)# mofrr rib acl1
Enter the ACL name.
Step 4
end or commit class-map
Example:
RP/0/RP0/CPU0:router(pim)# commit
Saves the configuration changes.
