Cisco XR 12000 Series Configuration Guide

Implementing Multicast Routing on Cisco IOS XR Software Cisco ASR 9000 Series Routers
Configuration Examples for Implementing Multicast Routing on Cisco IOS XR Software
MCC-69
Multicast Configuration Guide
OL-
Configuring IPv4 Multicast VPN: Example
only IPv4 addressing.
This end-to-end configuration example shows how to establish a multicast VPN topology (Figure 9),
using two different routing protocols (OSPF or BGP) to broadcasting traffic between customer-edge(CE)
routers and provider-edge (PE) routers:
• Configuring MVPN to Advertise Routes Between the CE and the PE Using OSPF: Example,
page MCC-69
• Configuring MVPN to Advertise Routes Between the CE and the PE Using BGP: Example,
page MCC-74
Figure 9 Topology in MVPN Configuration on the Example
For more configuration information, see the “Configuring Multicast VPN” section on page MCC-40 of
this module and also related configuration information in Cisco IOS XR Routing Configuration Guide.
Configuring MVPN to Advertise Routes Between the CE and the PE Using OSPF: Example
PE1:
!
vrf vpn1
address-family ipv4 unicast
import route-target
1:1
!
export route-target
1:1
!
!
!
interface Loopback0
ipv4 address 1.1.1.1 255.255.255.255
!
interface Loopback1
vrf vpn1
ipv4 address 2.2.2.2 255.255.255.255
!
interface GigabitEthernet0/5/0/0
vrf vpn1
ipv4 address 101.1.1.1 255.255.255.0
!
interface TenGigE0/6/0/0
ipv4 address 12.1.1.1 255.255.255.0
!
mpls ldp
router-id 1.1.1.1
interface TenGigE0/6/0/0
!
!
multicast-routing
CE4
PE 1
PE 2
CE3
