Citizen CL-S321 Series User Manual

CL-S321 Series Service Manual
- 15 -
(6)“SA FEED SWICH SP 321(PPT00011-00)”
Open the top cover. The LED guide rod and the
button are held by three screws.
Take out the screws and lift up.
In order to reach the FEED switch module, open
the bottom cover.
Lift up the bottom cover gently from the cut-out portion
by using a flat-head screw driver.

Citizen CL-S321 Series Specifications

General

Brand	Citizen
Model	CL-S321 Series
Category	Label Maker
Language	English
