CL-S321 Series Service Manual
- 11 -
(4)“SA PLATEN SP 321(PPK90017-00)”
Unscrew and take out 3 screws on the bottom
cover.
Lift up the bottom cover gently from the cut-out portion
by using a flat-head screw driver.
The main board is held by two points with the body
frame. One with a hole and one hook.
Pull up the main board.
<Assembly Order>
Hooks
