CL-S321 Series Service Manual
- 19 -
(8)“SA RIBBON HOLDER SP 321(PPM40002-00)”
*Note that this part does NOT include sensors, the print head or the lower mechanism.
Open the top cover and unscrew to release the
TPH.
Unscrew and take out the ESD cable.
The TPH cover has two hooks on the both
sides. Push them to take out the TPH cover.
Unscrew to release the TPH and unplug the
TPH connector.
Put on gloves and do not touch the TPH with bare hands
when handling.
