Citizen CL-S321 Series - Sa Ribbon Sensor Sp 321(Pps00176-00)

CL-S321 Series Service Manual
- 17 -
(7)“SA RIBBON SENSOR SP 321(PPS00176-00)”
Open the top cover. The LED guide rod and
the button are held by three screws.
Take out the screws and lift up.
Open the bottom cover.
Lift up the bottom cover gently from the cut-out portion by
using a flat-head screw driver.
