Printer Operation
24
* Use a transparent sensor for label media gaps and media with black marks.
* Use a transparent sensor for fan fold media.
* If the label pitch is 1 inch or less, set the Small Media Adjustment menu to ON and
match it to the label that uses the value of the Small Media Length menu.
Menu Setting Table (p.43)
Minimum value mm (in) Maximum value mm (in)
A Label width 7.62 (0.3) 118.00 (4.65)
B Liner width 25.40 (1.0) 118.00 (4.65)
C Left end of label 0 (0) 2.54 (0.10)
D Gap between labels 2.54 (0.10) 812.80 (32.00)
E Label length 6.35 (0.25) 812.80 (32.00)
F Label pitch 6.35 (0.25) 812.80 (32.00)
G Liner thickness 0.06 (0.0025) 0.125 (0.0049)
H Media thickness 0.06 (0.0025) 0.25 (0.01)
I Right end of notch 8.3 (0.32) 11 (0.43)
J Left end of notch 0 (0) 4.7 (0.19)
K Notch length 2.54 (0.10) 17.80 (0.70)
L Right end of black mark 15.00 (0.59) — —
M Left end of black mark 0 (0) 1.5 (0.06)
N Black mark width 3.18 (0.125) 17.80 (0.70)
Setting the Media
When Using Front Sensors
* Use a transparent sensor for label media gaps and media with black marks.
* Use a transparent sensor for fan fold media.
* If the label pitch is 1 inch or less, set the Small Media Adjustment menu to ON and
match it to the label that uses the value of the Small Media Length menu.
Minimum value mm (in) Maximum value mm (in)
A Label width 25.24 (1.0) 118.00 (4.65)
B Liner width 25.24 (1.0) 118.00 (4.65)
C Left end of label 0 (0) 2.54 (0.10)
D Gap between labels 2.54 (0.10) 812.80 (32.00)
E Label length 12.70 (0.50) 812.80 (32.00)
F Label pitch 12.70 (0.50) 812.80 (32.00)
G Liner thickness 0.05 (0.0025) 0.125 (0.0049)
H Media thickness 0.05 (0.0025) 0.25 (0.01)
I Right end of notch 3.6 (0.14) 60.8 (2.39)
J Left end of notch 0 (0) 57.2 (2.25)
K Notch length 2.54 (0.10) 17.80 (0.70)
L Right end of black mark 15.00 (0.59) 66.5 (2.62)
M Left end of black mark 0 (0) 51.5 (2.02)
N Black mark width 3.18 (0.125) 17.80 (0.70)
When Using Adjustable Sensor
Menu Setting Table (p.43)
To Next Page
