61
Printer Adjustments
Moving the Adjustable Sensor
Menu Setting Table (p.43)
Ensure the adjustable sensor
is selected.
Operating procedure
Measure your required detection position beforehand, using the
scale on the upper guide rail. Move the adjustable sensor to the
required detection position by tuning the adjustable knob; it is
useful to align the yellow mark on the top of the adjustable sensor
with the scale showing the required detection position.
Adjustable knob
Scale
Mark (yellow)
Top view
59mm
(sensor usable range)
118mm (max. media width)
To Next Page
