Citizen CLP-521 Technical Manual

Chapter 1 Specifications
1-3 CLP-521, CLP-621 & CLP-631
Item Descriptions
Power consumption Typical operating: Approx. 1.5 A (24 V)
(Power is supplied from the printer.)
Operating temperature and
humidity
Temperature: 5 to 40°C (41 to 104°F)
Humidity: 30 to 75% RH (non-condensing)
(Condition: Under good ventilation with natural convection)
Note: Specifications for temperature and humidity are the
same as the printer.
Outer dimensions 149 mm (W) x 76 mm (H) x 52 mm (D)
(5.87” (W) x 2.99” H x 2.05” (D))
Weight Approx. 0.5 kg (1.1 lb.)
Note: When paper with adhesive is used, do not cut a label portion. Otherwise, adhesive
of label may stick onto the cutter blade, which could cause cutting malfunction.

Citizen CLP-521 Specifications

General

Print technology	Direct thermal
USB port	No
RS-232 interface	Yes
Optional connectivity	Ethernet
USB 1.1 ports quantity	1
USB 2.0 ports quantity	0
Connectivity technology	Wired
Power requirements	100 - 240V, 50 / 60Hz
Compatible operating systems	Windows 2000/XP
Flash memory	2 MB
Certification	UL, C-UL, FCC: class A, CCC, CE Marking
Internal memory	8 MB
Number of fonts	2
Built-in barcodes	PDF417, UPC-A, UPC-E
Built-in processor	32 Bit RISC
Mean cycles between failures (MCBF)	1000
Core diameter	25.4 mm
Media thickness	0.0635 - 0.254 mm
Maximum label width	104 mm
Maximum label length	812 m
Maximum roll diameter	127 mm
Supported paper width	19.5 - 118 mm

Weight and Dimensions

Depth	289 mm
Width	231 mm
Height	186 mm
