Chapter 3 Media and Ribbon
41
4 Media Setting
The printer is designed to easily load media. Open the printer cover and set media in the
following:
1. Push down the open lever to open the printhead.
2. Push down the open guide lever to lift the open guide up.
3. Insert the roll holder with the roll guide in the core of roll media. Load this onto the media holder and
push against the left side wall and secure roll media.
4 Media Settin
To Next Page
