Chapter 2 Printer Operation
30
4 Self-Test Mode & Hex Dump Mode
In this mode, self-test printing is performed, and you can check the current printer configuration
settings and print quality. After loading the media and ribbon, operate the printer in the following
way:
1. Turn ON the power switch while pressing and holding the FEED key.
When labels are used, hold down the FEED key for two seconds and the printer will feed the
media and print samples 1 and 2 (see below) and stop.
When continuous media is used, hold down the FEED key for four seconds and the printer will
feed the media and print samples 1 and 2 (see below) and stop.
4 Self-Test Mode & Hex Dump Mode
