Citizen CMP-40L

24
2.4 Using Battery Charger
Optional
Lamp
(1) Insert the battery into the battery cradle as shown above.
(2) Connect the DC plug to the battery cradle.
(3) Plug the AC cord into the electrical outlet.
(4) Once the charging is completed, remove the battery from the
cradle.
The status of lamp in charging
Status Charging Charging Completed
Charging Lamp Red Green
NOTE
Ifthebatteryisnotxedproperlyintheholder,theredlampwillbeblinking.
In such case, extract and reinsert the battery.
