5.3 Manual Setting of Memory Switch
Memory switches can be set manually or by a command.
For manual setting, refer to the next page.
The function of each memory switch is shown in the following table. (The
white-on-black characters are factory setting.)
Switch No. Setting 0 (OFF) 1 (ON)
Memory SW1-1 Power ON Info Send Not send
Memory SW1-2 Buffer Size 4k bytes 45 bytes
Memory SW1-3 Busy Condition Full/Err Full
Memory SW1-4 Receive Error Print “?” Invalid
Memory SW1-5 CR Mode Ignored LF
Memory SW1-6 Reserved Fixed −
Memory SW1-7 DSR Signal Invalid Valid
Memory SW1-8 Reserved Fixed −
Memory SW2-1 Reserved − Fixed
Memory SW2-2 Reserved Fixed −
Memory SW2-3 Spool print Invalid Valid
Memory SW2-4 Full col print LineFeed WaitData
Memory SW2-5 Resume aft PE Print next line Print top
Memory SW2-6 Reserved − Fixed
Memory SW2-7 Reserved Fixed −
Memory SW2-8 PNE sensor Valid Invalid
Memory SW3-1 Reserved Fixed −
Memory SW3-2 Reserved Fixed −
Memory SW3-3 Parallel 31 Pin Valid Invalid
Memory SW3-4 Reserved Fixed −
Memory SW3-5 Reserved Fixed −
Memory SW3-6 Reserved Fixed −
Memory SW3-7 CBM-270 mode Invalid Valid
Memory SW3-8 Resum Open Err Close Command
To Next Page
