8
How to order
AX2000T
Series
AX2000T
Actuator
H
Interface specifications
H
Interface specifications
( )
How to order
G
Body surface treatment
Note 3
E
Driver power voltage
Note 1
F
Dowel hole
Note 4, Note 5
B
Driver type
Model no.
A
Size (max. torque)
D
Cable length
Note 2
AX2 018 DM04 J1TS BS P1 U0S
Model Model no. of options
Symbol
Descriptions
A
Size (max. torque)
006 6 N•m
012 12 N•m
018 18 N•m
B
Driver type
TS TS type driver
C
Mounting base (can not be used with a dowel hole P2, P3.)
Blank Standard (without mounting base)
B With blackened mounting base
BS
Electroless nickel plating, surface treatment
mounting base Use with body surface treatment S.
E
Driver power voltage
Refer to a the left mentioned driver-power voltage table.
F
Dowel hole
Blank Standard (without dowel hole)
P1 1 on top
P2 1 on bottom
P3
1 each on both top and bottom
G
Body surface treatment
Blank Standard (blackening treatment)
S Electroless nickel plating
Note on model no. selection
Note 1:
Use the table below to select the appropriate driver.
Driver-power voltage table
Driver
Type
Model
TS type driver
Three phase and
single phase
200 230 to VAC
Single phase
100 115 to
VAC
AX2006T Blank J1
AX2012T Blank J1
AX2018T Blank J1
Note 2:
The cable is a flexible cable.
Refer to page 35 for dimensions of a cable. The body
outlet cable is not a flexible cable.
Note 3:
Designate surface treatment and mounting base
surface treatment with
C
and
H
. By selecting
the optional electroless nickel plating, higher
resistance to rusting can be expected.
Note 4: "P2" and "P3" cannot be selected if "B" with
blackened mounting base or "BS" electroless
nickel plating surface treatment mounting
base is designated for
C
Mounting base.
Note 5: Additionally machined sections may not have
a treated surface.
Set model no.(
actuator, driver, cable)
*Custom orders are not CE, UL/cUL, RoHS certified. Consult with CKD for details.
Discrete actuator body model no.
Discrete driver model no.
Discrete cable model no.
AX2 T SP1B
AX9000TS
U0
AX9000TS J1 U0
AX CBLM6 DM04
Three phase 200 to 230 VAC
Single phase 100 to 115 VAC
A
Size
C
Mounting base
G
Body surface
treatment
F
Dowel
hole
D
Cable change
Note: "04" for cable
length 4 m
Motor cable
Resolver cable
AX CBLR6 DM04
D
Cable length
DM02 2m
DM04 4m (standard length)
DM06 6m
DM08 8m
DM10 10m
DM15 15m
DM20 20m
H
Interface specifications
U0 Parallel I/O (NPN specifications)
U1
Parallel I/O (PNP specications)(Coming soon)
U2 CC-Link
U3
PROFIBUS-DP
U4 DeviceNet
C
Mounting base
Note 3, 4
