CKD AX1000T Series User Manual

15
AX4000T
Series
Dimensions
AX4009T

40.5×t21
110 35 50
of outlet cable is 30mm.
(Note) Min. bending radius
Note) Do not remove. The noise resistance could drop.
146±0.03
120±0.03
(Note): Fix the end of the cable
sheath when bending repeatedly.
2-Φ6H7
(Option)
4-Φ7
Φ5H7 depth 7
(Option)
Body outlet cable length 400 mm
This is not a flexible cable.
6.5
(5)
18
45
50
10
Φ170
Φ42
Φ42.5
30
Φ19.5
85
140 160
160
140
Φ150h7
Φ168
A
A
0.06
(Option dowel hole dimension)
(Option dowel hole dimension)
6-M5 depth 10 (straight)
For mounting dial plate
Fixed section
Rotating section
(including hollow section)
80
P.
C.D.160
Note 1) The origin of the actuator may differ from the dimensions shown above.
Origin can be configured randomly using the origin offset function.
