(Lifting)
(Downward bending
range is 125).
Not possible when using optional mounting base
4-Φ18
4-M12 (discrete mounting base lifting)
For mounting dial plate
8-M10 depth 20 (straight)
Mounting base (option)
440
380
PCD390
Φ10H7 depth 12 (option)
11
.25°
A0.06
M12 depth 24 05 4- (straight)
195
A
Φ420
Φ160h7
Φ85 (hollow)
Cable bending range
145
Fixed section
25
B
(11)
243
Φ350h7
2-M4
GND for mounting
Φ435±4
6.526
30
°
116
200
6-M12 depth 25 (straight)
Platform for mounting
P.
C.D.400
Φ10H7 depth 12 (option)
B
47.5
(20)
(Note): Fix the end of the cable
sheath when bending repeatedly.
(Including hollow section)
Rotating section
320
380
440
275
24015
36.5
44
0.06
PCD 101
C15
Note 1) The origin of the actuator may differ from the dimensions shown above.
Origin can be configured randomly using the origin offset function.
