CKD EVD Series User Manual

EVD Series
9
Cable option dimensions
EVD-C1, EVD-C3
EVD-P1, EVD-P3
1000
3000
30.7
31.5
100
9-AWG26
Shield wire
( 6)
1000
3000
( 6.5)
31.5
30.7
100
15-AWG26
Shield wire
*Connect the shield wire to the
power's minus (0 V) side.
*Connect the shield wire to the
power's minus (0 V) side.
12
Isolator color
-
13
Green Blue
4 to 20
mADC
0 to 5
VDC
11
White
10
Gray
9876
-
5
Red
4
-
3
Yellow
2
Orange
1
D sub
socket
pin no.
Brown
14
Black
15
Preset input signal
Input signal
Bit 1 Bit 1 Bit 1
Vacant
+
24VDC
Power
supply+
Vacant
--
Vacant Vacant Vacant
-
Common
0 to 10
VDC
Vacant
Vacant
Monitor
output
Output short-circuit
protection circuit
1 to 5 VDC
Switch
output
NPN or PNP output
Error
output
NPN or PNP output
Power supply-
(0V)
Type of input
Isolator color
13
Green Blue
Bit 10
11
White
10
Gray
98765
Red
Light blue
Pink
White
(with a black line)
4
Purple
3
Yellow
2
Orange
1
D sub
Socket
Pin no.
Brown
12 14
Black
15
Bit 1
Bit 2 Bit 3 Bit 4
Bit 5 Bit 6 Bit 7 Bit 8
+
24VDC
Red
(with a black line)
Green
(with a black line)
Common
Bit 9
Output short-circuit
protection circuit
1 to 5 VDC
Parallel input signal Parallel input signal Parallel input signal
Power
supply+
Monitor
output
Switch
output
Error
output
NPN or PNP output NPN or PNP output
Power supply-
(0V)
Type of input
Name
Name
