CKD EVD Series User Manual

RUN mode Display descriptions table
F1 (input signal selection) Screen F1 display details
F2 (Zero/span adjustment function) Screen F2 display details
Input signal type symbols
<Analog input type>
EVD- -0 - - , EVD- - - - , EVD- -2 - -
Analog 0 to 10 VDC input
Analog 0 to 5 VDC input
Analog 4 to 20 mA DC input
Direct memory input
Input signal type symbols
to
Descriptions
Objective values
(pressure conversion)
Parallel 10bit input
Direct memory input
Input signal type symbols Descriptions
<Digital input type>
EVD- -P - -
When invalid
F3 (automatic power off) Screen F3 display details
The validity of automatic power off is confirmed.
When invalid
When valid
When valid
Preset memory input
Selected preset no. is displayed.
The validity of zero/span adjustment and the setting are confirmed.
Note: This is invalid if preset or direct memory input is selected for F1 mode.
F4 (switch output function) Screen F4 display details
Switch output validity and setting are confirmed.
Note: This is invalid with analog output specifications.
Span point
adjustment
Set value (%)Zero
adjustment
Set value (%)
For mode 2
Upper
limit side
Set value (%)Lower
limit side
Set value (%)
For mode 1
When invalid
- allowable
side
Set value (%) + allowable
side
Set value (%)
The input signal type and target value are alternately displayed.
When invalid
Input signal
100%
0%
0% 100%
Control pressure
When valid
Input signal
100%
0%
0% 100%
Zero point (L) setting range
0 to 50%
Span point (H) setting range
100 to 10%
H (+ allowable side)
Input signal setpoint
L (- allowable side)
<Mode 1>
Output
ON ON ON
OFF OFF OFF
H (upper limit side)
L (lower limit side)
<Mode 2>
Output
ON ON ON
OFF OFF OFF
14
EVD Series
How to operate
How to operate
