[9]How to order
FSM2 - N V R 005 - S06 AR 1 B K N - P70
[1] [2] [3] [4] [5] [6] [7] [8] [9] [10] [11]
[1]Output type [2]Analog output type [3]Flow direction [4]Flow rate range (full scale flow rate)
V 1 to 5V F Bi-directional 005 500 mL/min
A 4 to 20mA 010 1 L/min
N Integrated indicator type
Switch output(NPN): 2points
Analog output: 1point
020 2 L/min
050 5 L/min
100 10 L/min
P Integrated indicator type
Switch output(PNP): 2points
Analog outpot: 1point
200 20 L/min
500 50 L/min
101 100 L/min
201 200 L/min
[5]Port size(body material) [6]Working fluid [7]Cable [8]Bracket [9] Traceability
H04 Φ4 push-in (resin) Blank Air, Nitrogen gas Blank None Blank None Blank None
H06 Φ4 push-in (resin) AR Argon 1 1m B With bracket
H08 Φ4 push-in (resin) C2 Carbon dioxide 3 3m P Panel mount
T
Traceability certificate, system diagram,
inspection results included
H10 Φ4 push-in (resin) K Inspection results included
S06 Rc1/8 (stainless)
S08 Rc1/4 (stainless)
[10]Needle valve [11]Clean
Ｎ
Needle valve Blank none
P70 Particle occurrence prevention
P80 Oil treatment prohibited
・Combination of flow rate range, port size, and working fluid
[5]Port size(body material)
H04 H06 H08 H10 S06 S08
005
● ●
●○△
010
● ●
●○△
020
● ●
●○△
050
● ●
●○△
100
● ●
●○△
200
● ●
●○△
500
● ●
●○ ●○△
101
● ●
●○△
[4]Flow rate range
201
● ●
●
・Table for clean specification
[5]Port size(body material)
Ｈ０４ Ｈ０６ Ｈ０８ Ｈ１０ Ｓ０６ Ｓ０８
Ｐ７０ ● ● ● ● ● ●
[11]Clean
Ｐ８０ ● ● ● ●
Discrete option model
FSM2 - LB1-P70
[ 12 ] [ 13 ]
[12]Option
[13]Clean
LB1 Bracket (for port sizeΦ4,6,8,10, Rc1/8, Rc1/4,)
Blank none
C51 1m (for Integrated indicator type)
P70
Particle occurrence prevention
C53 3m (for Integrated indicator type)
KHS-N Panel mount kit
CKD Corporation
2-250, Ouji, Komaki, Aichi 485-8551, Japan
http://www.ckd.co.jp
We reserve the right to change dimensions, specifications and design without notice.
2008.6.9
Rev 2009.6.8
[11]Clean
● ： Lineup
： None
[6]Working fluid
● : Air, Nitrogen gas
○ :
Argon
△ : Carbon dioxide
: None
