CKD RAPIFLOW FSM2 N Series User Manual

[7] Specifications
Integrated indicator type (Resin body)
Note1: Converted to volumetric flow at 20°C and 1 atmospheric pressure (101kPa)
Note2: Flow late display is only the read within rough±1%F.S.
Note3: Integranted flow display is reference value.
Note4: When using compressed air, use clean air complying with JIS B 8392-1:2003 class over 1.1.1 to 1.6.2. Compressed air from the compressor contains drainage (water, oxidized oil,
foreign matter, etc.). Install a filter（filtration rating：5µm）, air dryer（minimum pressure dew point 10℃ or less） and oil mist filter(maximum oil concentration 0.1mg/m
3
) on the primary
side of the product to maintain product function.
When using for purposes other than compressed air, use dry gas that does not contain corrosive elements such as chlorine, sulfur or acids, and clean gas that does not contain dust
or oil mist.
Note5: The response time can be selected from 50ms to 1500ms.
Note6: Current consumption is different according to the state of the load.
Note7: Integrated flow value is reset by turning power off.
Note8: Current consumption is characteristics 24VDC and no load. It is changed by load. Please note it.
Note9: This product’s protective circuit is effective only for specific incorrect connections and load short-circuits. It does not necessarily provide protection for all incorrect connections.
Note10:<P70>Particle occurrence prevention (It is washing of remove fat to surface of product before it wraps it. And heat seal wrapping to antistatic bag inside clean work
station.(Class:100 or more ))
Note11:<P80>Oil treatment prohibited (In addition to the P70 specification, It is washing of removing fat to touching gas. Please refer, Touching gas material is internal structural chart.)
Model no.
Descriptions
Integrated needle valve type ( Resin body)
FSM2-[*1][*2][*3][*4]-[*5]N-[*6]
Full scale flow rate 005 010 020 050 100 200 500 101 201
005 500mL/min
●
010 1L/min
●
020 2L/min
●
050 5L/min
●
100 10L/min
●
200 20 L/min
●
500 50 L/min
●
101 100 L/min
●
Full scale
flow rate
Note 1
*4
201 200 L/min
●
H04 Φ 4 push-in / resin
● ● ● ● ● ●
H06 Φ 6 push-in / resin
● ● ● ● ● ● ●
H08 Φ 8 push-in / resin
● ● ●
Poet size/
Body
material
*5
H10 Φ 10 push-in/ resin
● ●
Type of display Dual (2×4-digit 7-segment) Two-color LCD
Flow rate
range
*3 F
0 to
500
mL/min
0 to
1000
mL/min
0 to
2.00
L/min
0 to
5.00
L/min
0 to
10.00
L/min
0 to
20.0
L/min
0 to
50.0
L/min
0 to
100.0
L/min
0 to
200
L/min
Flow rate display
Note 1,2
Display resolution 1mL/min 0.01L/min 0.1L/min 1L/min
Flow rate range 9999999mL 99999.99L 999999.9L 9999999L
Display resolution 1mL 0.01L 0.1L 1L
Integrating
function
Note 3,7
Integrating pulse output rate
5mL 10mL 0.02L 0.05L 0.1L 0.2L 0.5L 1L 2L
Working fluid Note 4
Clean air
(JIS B 8392-1.1.1 to 5.6.2), Compressed air (JIS B 8392-1.1.1～ 1.6.2), and Nitrogen
gas
Maximum working pressure 0.7MPa
Minimum working pressure -0.09MPa
Withstanding pressure 1.0MPa
Ambient temperature / humidity 0 to 50°C and 90%RH or less
Working
conditions
Working fluid tem perature 0 to 50°C (to be no dew condensation.)
Flow rate range 3 to 100%F.S.
Linearity (display / analog output) ±3%F.S. or less (25°C, 1 atmospheric pressure)
Pressure characteristics ±5% F.S. or less (-0.09 to 0.7MPa, 25°C, 1 atmospheric pressure criteria)
Tem perature characteristics ±0.2% F.S./°C or less (15 to 35°C, 25°C criteria)
Accuracy
Repeatability ±1%F.S. or less
Response time Note3 50ms or less
N 2 points (NPN open collector output, 50mA or less, voltage drop 2.4V or less)
Switch output *1
P 2 points (PNP open collector output, 50mA or less, voltage drop 2.4V or less)
V 1 point (1 to 5V voltage output and connected load impedance 50kΩ and over)
Output
Analog output *2
A
1 point (4 to 20mA current output and connected load impedance 300Ω or
less)
V DC12／ 24V (10.8 to 26.4V)
Power supply voltage *2
A DC24V (21.6 to 26.4V)
Current consumption Note8 50mA or less
Lead wire φ 3.7 AW G26×5
Functions
Flow rate display, flow rate display-peak hold, switch output and analog output，
Outside diam eter of insulator is Φ 1.0
Installation attitude Both vertical and horizontal
Strait piping section Not required
Protective structure IEC standards IP40
Protective circuit Note9
Power supply and switch output reverse connection protections, and switch
output load short-circuit protection
EMC instruction Acceptable goods
H04 Approx. 80g
H06 Approx. 80g
H08 Approx. 110g
Mass
（Only the m ain body）
*5
H10 Approx. 115g
P70 Particle occurrence prevention Note10
Clean specification *6
P80 Oil treatment prohibited
Note11
－8－
Discontinue
