9.3 ANALOGUE INPUT SETTINGS
The inputs identified by AI1, AI2, AI3 and AI4 are analogue inputs.
1. Click on " Inputs" to display the input configuration page.
2. To activate an input that is not displayed on the list, select "Show disabled ports".
The list will show disabled inputs
with a gray background.
3. Click on an input to reach its configuration page.
1.
2.
3.
