CELTIS 10.2007
GB
B.3
INSTRUMENTS AND CONTROLS (PANEL)
761bsn02
Installation
A
- With "REVERSHIFT" electrohydraulic drive inverter.
Installation
B
- With mechanical drive inverter.
1-
Hydroelectric forward/reverse lever (REVERSHIFT) .
2-
Air vents.
3-
Instrument cluster.
4-
Rotating light control button.
5-
Emergency alarm button.
6-
Mechanical range doubler lever.
7-
Main switch (key operated).
8-
Windscreen wipers.
9-
Windscreen washers.
10 -
Direction indicators, lighting and warning lights.
11 -
ventilation /air conditioning control panel.
12 -
Steering wheel height/angle adjustment control.
13 -
Digital clock adjustment knob (assembly
B
).
14 -
Mechanical drive reverser lever.
1
11
10
7
9
2
3
2
4
5
12
8
14
6
8
9
13
A B
