Claas LEXION 540 C Repair Manual Supplement

00 0290 380 0 - ERG RHB LEXION 600-510 - 01/09 13
3 Straw discharge
3.2 Straw spreader
82706
Heading
A Overview of straw spreader.
B Removing / installing the straw spreader drive
hydraulic motor (223).
C Removing / installing / adjusting belt (R17).
Pos. M
A
(Nm)
Auxiliary utilities Remarks
1 - 8 90 Nm – Removing / installing toothed belt pulleys
(5 - 8):
- Remove belt (R17).
- Unscrew tensioning screws (1 - 4).
- Screw tensioning screws (1 - 4) into the free
tapped holes until the lock collars are slack-
ened off.
- Pull off toothed belt pulleys (5 - 8).
- Clean toothed belt pulleys (5 - 8), the lock
collars and the shaft ends so they are free of
grease.
- Pre-assemble toothed belt pulleys (5 - 8)
with lock collars and slide them on the shaft
ends.
- Align toothed belt pulleys (5 - 8) towards
one another, using a ruler.
- Arrest lock collars with tensioning screws
(1 - 4).
Tightening torque = 90 Nm
- Install and adjust belt (R17).
9 130 Nm
10, 11 40 Nm
12 Silicone sealing compound, e.g.:
Silicone rubber
Part no. 00 0136 544 0
Seal corners (12) with silicone sealing compound.
13, 14 Adjust dimension (X) between belt and ball bearing
(13) at the eccentric (14) with belt (R17) tensioned.
15, 16,
17
Install brackets (15) with an offset dimension (Y)
between them.
Check free rotation of wings (16) and (17).
M
A
= Tightening torque
Pos. Designation Dimensions Remarks
X Adjustment dimension 1.2 mm
Y Adjustment dimension 60°
