Claas MEDION 310 - Page 43

299 216.0 - RHB MEDION 340 - 310 2.1.5
Cab
5. Screw the roof liner (L) to the top windscreen
frame at the front edge, using four self-tapping
screws.
(Fig. 15)
6. Bolt down clamp (H) and hex. bolt (K).
(Fig. 16)
7. Bolt down panel (G).
(Fig. 17)
8. Bolt down the doors (F) to the hinge on the side
panel on the left and right side.
(Fig. 18)
L
15
K
H
16
G
17
F
18
