2.1.6 RHB MEDION 340 - 310 - 299 216.0
Cab
9. Slide on the air inlet nozzles (E) on the left and
right side.
(Fig. 19)
10. Screw the wiper motor (D) to the windscreen.
11. Fit the windscreen wiper (B).
(Fig. 20)
12. Bolt down panel (A).
(Fig. 21)
Removing the cab rear panel
Unlock the operator's seat and pull it fully to the front.
Fold away the seat back.
On the left-hand side unscrew panel (A).
Unscrew panels (B and C).
(Fig. 22)
E
19
D
B
20
A
21
B
C
A
22
