6 00 0294 514 0 - RHB QUADRANT 3400 - 03/10
Introduction
General repair instructions
81213
General repair instructions
2475
Specifications
Technical data, dimensions and weights are given as
an indication only. CLAAS reserves the right to make
changes subsequently as technical developments con-
tinue. Responsibility for errors or omissions not
accepted.
14015
Reason of damage
Identify reason of damage, limit the case of damage
and safeguard the machine.
115321
Spare parts
Use CLAAS original parts and the corresponding spe-
cial tools.
For any spare parts orders or technical requests, indi-
cate the machine serial number and, if applicable, the
equipment serial number. This measure is necessary
to prevent incorrect spare parts deliveries.
Use only CLAAS original spare parts, accessories and
tools that have been inspected and approved by
CLAAS. Only these measures can ensure that the
properties defined in the design of CLAAS harvesting
machines, as well as their operating capacity, are
maintained. CLAAS original parts also maintain active
and / or passive driving safety, as well as machinery
working safety.
CLAAS disclaims all liability in the event of damage
resulting from the use of parts, accessories and equip-
ment that are not CLAAS original products.
14021
Gearboxes
When dismounting the gearboxes, always drain the
transmission oil first and then remove the gearbox.
Separate parts sticking firmly together with a soft
metal-tip or plastic-tip hammer.
14045
Welding Work
115323
Tensioning the steel roller chains
The steel roller chains are correctly tensed when you
can push down the slack section with your thumb by
around 2% of its length (gear interaxial distance), while
the tense strand is under low stress. Verify the tension
on new chains more often.
Note!
All information regarding this subject-matter
can be found in the current Operator's manual
of the machine.
