Clack Valve WS1.25 User Manual

Page 6 WS1 & 1.25 Man u al
4
Total time does not include  ll time, which is dependent upon the amount of  ll needed. When in the  ll mode the system is
providing treated water.
5
See Installer Display Settings Step 3I, OEM Softener Setup Step 6S and OEM Filter Setup Step 5F for ex pla na tions of Day
Over ride and Gallon Capacity.
The control valve with a water meter can be set for Demand Initiated Regeneration (DIR) only, Time Clock operation only
or DIR and Time Clock which ever comes  rst, depending upon what settings are selected for Day Override and Gallon
Capacity.
5
See Table 7.
If a control valve does not contain a meter, the valve can only act as a time clock, and day override should be set to any
number and gallon capacity should be set to off.
WS1 & WS1.25 Downfl ow
Regenerant Refi ll After Rinse
WS1 & WS1.25 Downfl ow
Regenerant Prefi ll
WS1 & WS1.25
No Regeneration
1
st
Cycle: Backwash
2
nd
Cycle: Regenerate
3
rd
Cycle: Second Backwash*
4
th
Cycle: Rinse
5
th
Cycle: Fill
6
th
Cycle: Service
1
st
Cycle: Fill
2
nd
Cycle: Backwash
3
rd
Cycle: Regenerate
4
th
Cycle: Second Backwash*
5
th
Cycle: Rinse
6
th
Cycle: Service
1
st
Cycle: Backwash
2
nd
Cycle: Rinse
3
rd
Cycle: Second Backwash*
4
th
Cycle: Second Rinse**
5
th
Cycle: Service
Table 4
Regeneration Cycles Filtering
*Second backwash is optional
**Second rinse only occurs if Second Backwash option is selected.
Table 5
Regenerating Filter
Cycle Times in Minutes
WS1 & WS1.25 Single Backwash WS1 & WS1.25 Double Backwash
Normal Longer Normal Longer
Backwash 14 16 8 12
Regenerate 60 60 60 60
2
nd
Backwash
10 12
Rinse 8 10 8 10
Total
4
82 86 86 94
Table 6
Non-Regenerating Filter
Cycle Times in Minutes
WS1 & WS1.25 Single Backwash WS1 & WS1.25 Double Backwash
Normal Longer Normal Longer
Backwash 14 16 8 12
Rinse 8 10 6 6
2
nd
Backwash
10 12
2
nd
Rinse
810
Total 22 26 32 40
