Clack CF1044-3B - Engineering Data

F I L O X S e r i e s F i l t e r
Installation Operation Maintenance Manual
FILOXWS1-3B APRIL 2011 \page 20
11.2 ENGINEERING DATA
FILOX Series Filters
PRESSURE 1.7 Bar MAXIMUM OPERATING TEMPERATURE
45.0C HEADROOM - Allow 100 mm greater than overall height.
MODEL CF1044-
3B
CF1248-
3B
CF1354-
3B
CF1465-
3B
VALVE
FILTER
VESSEL
1054 1248 1354 1465
HEIGHT
(MM)
1607 1458 1601 1984
DIAMETER
OF VESSEL
(MM)
254 305 331 356
VALVE
INLET
1”
VALVE
OUTLET
1”
VALVE
DRAIN
¾”
QTY
GRAVEL
0.25 0.5 0.75 1.5
QTY FILOX 2 3 4 5
POWER 240 VAC 1.2 VA
