Clarion ADB341MP User Manual

ADB340MP
ADB341MP
- 1 -
Published by Service Dept.
Printed in Japan
Clarion Co., Ltd.
50 Kamitoda, Toda-shi, Saitama 335-8511 Japan
Service Dept.: 5-66 Azuma , Kitamoto-shi, Saitama 364-0007 Japan
Tel: +81-48-541-2335 / 2432 FAX: +81-48-541-2703
298-6153-00
Mar.2004 P
Service Manual
Model
2DIN AM/FM
CD/MP3 Cassette Player
SPECIFICATIONS
FM tuner section
Frequency range: 87.9MHz to 107.9MHz
(ADB340MP)
87.0MHz to 108MHz
(ADB341MP)
Usable sensitivity: 11dBf
50dB quieting sensitivity:17dBf
Alternate channel selectivity:
75dB
Stereo separation: 35dB (1kHz)
Frequency response: 30Hz to 15kHz (+/-3dB)
AM tuner section
Frequency range: 530kHz to 1710kHz (ADB340MP)
531kHz to 1629kHz (ADB341MP)
Usable sensitivity: 25uV
CD player section
Frequency response: 10Hz to 20kHz (+/-1dB)
S/N ratio: 100dB (1kHz)
Dynamic range: 95dB (1kHz)
Distortion: 0.01%
MP3 mode
MP3 sampling rate: 8kHz to 48kHz
MP3 bit rate: 8kbps to 320kbps/VBR
Logical format: ISO9660 level1,2
JOLIET or Romeo
Tape deck section
Wow & flutter: 0.06%(WRMS)
Channel separation: 45dB(1kHz)
Frequency response(+3/-3dB):
120us(normal); 30Hz to 18kHz
Audio section
Maximum power output: 50Wx4
Continous average power output:
17Wx4, into 4ohm, 20Hz to 20kHz,
1%THD
Bass control action: +/-10dB (100Hz)
Middle control action: +/-10dB (1kHz)
Treble control action: +/-10dB (10kHz)
Line output level: 18V (CD 1kHz)
EQ
4mode: Impact / B-boost / Accustic / Flat
General
Power supply voltage: 14.4V DC(10.8V to 15.6V allow-
able) negative ground
Current consumption: Less than 15A
Speaker impedance: 4ohm(4ohm to 8ohm allowable)
Dimensions(mm): 178(W)x100(H)x183(D)
Weight: 2.1kg
(PE-2652B-A / For U.S.A.)
NOTES
* In extreme cold, the screen movement may slow down
and the screen may darken, but this is normal.The screen
will recover when it returns to normal temperature.
* Use only compact discs bearing the or mark.
* Some CDs recorded in CD-R/CD-RW mode may not be
usable.
* We cannot supply PWB with component parts in principle.
When a circuit on PWB has failure, please repair it by
component parts base. Parts which are not mentioned in
service manual are not supplied.
* Specifications and design are subject to change without
notice for further improvement.
(PE-2653K-A / For other countries)
Model
