Clarion ADB341MP User Manual

ADB340MP
ADB341MP
- 15 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ELECTRICAL PARTS LIST
Main PWB(B1) section
AJ201 653-0428-57 ANT JACK ASSY
C201 653-0428-58 1000PF 50V
C202 653-0428-59 0.01UF 50V
C203 653-0428-60 0.047UF 16V
C204 653-0428-61 5PF 50V
C205 653-0428-62 0.027UF 25V
(for ADB340MP)
653-0434-06 0.018UF 25V
(for ADB341MP)
C206 653-0428-62 0.027UF 25V
(for ADB340MP)
653-0434-06 0.018UF 25V
(for ADB341MP)
C207 653-0428-58 1000PF 50V
(for ADB340MP)
653-0428-96 0.22UF 25V
(for ADB341MP)
C208 653-0428-63 33PF 50V
C209 653-0428-64 220UF 10V
C210 653-0428-59 0.01UF 50V
C211 653-0428-59 0.01UF 50V
C311 653-0428-65 15PF 50V
C312 653-0428-65 15PF 50V
C313 653-0428-66 0.1UF 16V
C321 653-0428-58 1000PF 50V
C362 653-0428-67 0.1UF 16V
C363 653-0428-68 10UF 16V
C364 653-0428-67 0.1UF 16V
C365 653-0428-59 0.01UF 50V
C366 653-0428-67 0.1UF 16V
C371 653-0428-66 0.1UF 16V
C372 653-0428-66 0.1UF 16V
C373 653-0428-66 0.1UF 16V
C374 653-0428-66 0.1UF 16V
C375 653-0428-68 10UF 16V
C376 653-0428-68 10UF 16V
C381 653-0428-69 470PF 50V
C382 653-0428-69 470PF 50V
C383 653-0428-69 470PF 50V
C384 653-0428-69 470PF 50V
C386 653-0428-70 33UF 10V
C387 653-0428-70 33UF 10V
C388 653-0428-70 33UF 10V
C389 653-0428-59 0.01UF 50V
C390 653-0428-59 0.01UF 50V
C391 653-0428-71 4.7UF 16V
C392 653-0428-71 4.7UF 16V
C393 653-0428-58 1000PF 50V
C394 653-0428-72 0.1UF 50V
C395 653-0428-68 10UF 16V
C396 653-0428-73 1UF 50V
C398 653-0428-70 33UF 10V
C401 653-0428-74 1UF 10V
C402 653-0428-74 1UF 10V
C403 653-0428-74 1UF 10V
C404 653-0428-74 1UF 10V
C405 653-0428-74 1UF 10V
C406 653-0428-74 1UF 10V
C407 653-0428-68 10UF 16V
C408 653-0428-75 47UF 16V
C409 653-0428-68 10UF 16V
C410 653-0428-73 1UF 50V
C411 653-0428-76 220PF 50V
C412 653-0428-66 0.1UF 16V
C413 653-0428-68 10UF 16V
C414 653-0428-68 10UF 16V
C415 653-0428-77 0.15UF 10V
C416 653-0428-77 0.15UF 10V
C417 653-0428-59 0.01UF 50V
C418 653-0428-59 0.01UF 50V
C419 653-0428-78 820PF 50V
C420 653-0428-78 820PF 50V
C421 653-0428-68 10UF 16V
C422 653-0428-79 0.033UF
C423 653-0428-68 10UF 16V
C424 653-0428-78 820PF 50V
C425 653-0428-78 820PF 50V
C426 653-0428-59 0.01UF 50V
C427 653-0428-59 0.01UF 50V
C428 653-0428-77 0.15UF 10V
C429 653-0428-77 0.15UF 10V
C430 653-0428-68 10UF 16V
C431 653-0428-68 10UF 16V
C432 653-0428-66 0.1UF 16V
C433 653-0428-76 220PF 50V
C434 653-0428-73 1UF 50V
C441 653-0428-74 1UF 10V
C442 653-0428-74 1UF 10V
C455 653-0428-80 100UF 16V
C456 653-0428-67 0.1UF 16V
C501 653-0428-81 2.2UF 50V
C502 653-0428-81 2.2UF 50V
C503 653-0428-81 2.2UF 50V
C504 653-0428-81 2.2UF 50V
C505 653-0428-82 1UF 10V
C506 653-0428-82 1UF 10V
C507 653-0428-82 1UF 10V
C508 653-0428-82 1UF 10V
C509 653-0428-75 47UF 16V
C510 653-0428-83 22UF 16V
C511 653-0428-84 0.22UF 50V
C512 653-0428-85 0.1UF 50V
C513 653-0428-86 3300UF 16V
C551 653-0428-87 100PF 100V
C552 653-0428-88 0.1UF 50V
C561 653-0428-89 0.47UF 50V
C581 653-0428-90 2200PF 50V
C582 653-0428-90 2200PF 50V
C583 653-0428-90 2200PF 50V
C584 653-0428-90 2200PF 50V
C585 653-0428-90 2200PF 50V
C586 653-0428-90 2200PF 50V
C587 653-0428-90 2200PF 50V
C588 653-0428-90 2200PF 50V
C601 653-0428-85 0.1UF 50V
C611 653-0428-91 100UF 10V
C612 653-0428-67 0.1UF 16V
C622 653-0428-67 0.1UF 16V
C623 653-0428-91 100UF 10V
C624 653-0428-85 0.1UF 50V
C625 653-0428-67 0.1UF 16V
C627 653-0428-91 100UF 10V
C628 653-0428-67 0.1UF 16V
C631 653-0428-80 100UF 16V
C632 653-0428-67 0.1UF 16V
C633 653-0428-67 0.1UF 16V
C634 653-0428-80 100UF 16V
C641 653-0428-67 0.1UF 16V
C643 653-0428-67 0.1UF 16V
C652 653-0428-67 0.1UF 16V
C703 653-0428-92 0.1F
C705 653-0428-67 0.1UF 16V
C706 653-0428-67 0.1UF 16V
C707 653-0428-93 12PF 50V
C708 653-0428-94 10PF 50V
C709 653-0428-58 1000PF 50V
C710 653-0428-95 100PF 50V
C711 653-0428-95 100PF 50V
C712 653-0428-95 100PF 50V
C713 653-0428-96 0.22UF 25V
C714 653-0428-67 0.1UF 16V
C715 653-0428-59 0.01UF 50V
C716 653-0428-97 2.2UF 50V
C717 653-0428-67 0.1UF 16V
C718 653-0428-58 1000PF 50V
C720 653-0428-64 220UF 10V
C791 653-0428-59 0.01UF 50V
C792 653-0428-59 0.01UF 50V
C793 653-0428-59 0.01UF 50V
C794 653-0428-59 0.01UF 50V
C795 653-0428-59 0.01UF 50V
D201 653-0428-98 MA-301(MS)AT
D363 653-0428-99 MTZJ5.6T-C
D364 653-0429-01 MTZJ9.1T-C
D365 653-0429-02 MTZJ4.7T-B
D601 653-0429-03 1N5402
D602 653-0429-04 1SS244T
D611 653-0429-01 MTZJ9.1T-C
D621 653-0429-05 MTZJ6.2T-C
D622 653-0428-99 MTZJ5.6T-C
D623 653-0429-06 1SS355T
D624 653-0429-06 1SS355T
D641 653-0429-07 MTZJ10T-C
D642 653-0429-01 MTZJ9.1T-C
D662 653-0429-08 MTZJ8.2T-B
D664 653-0429-09 MTZJ7.5T-A
D665 653-0429-10 MTZJ6.8T-B
D731 653-0429-11 RB521S-30T
ET201 653-0428-13 TUNER PACK
(for ADB340MP)
653-0434-01 TUNER PACK
(for ADB341MP)
F301 653-0429-12 HQS-3H-10000-10
F701 653-0429-13 HQS-3H-06300-14
IC303 653-0429-14 M30621M8A8E7GP
IC351 653-0429-15 BA3430FS-CT
IC361 653-0429-16 LB1641
IC371 653-0429-17 BA3834F-CT
IC401 653-0429-18 LC75410W
IC451 653-0429-19 LA6458ML-CT
IC452 653-0429-19 LA6458ML-CT
IC501 653-0429-20 TA8275H
IC631 653-0429-21 KIA7806API
IC701 653-0429-22 UPD178078GF-667
J561 653-0429-23 0OHM 1/16W
J601 653-0429-23 0OHM 1/16W
J604 653-0429-23 0OHM 1/16W
J605 653-0429-24 0OHM 1/8W
J606 653-0429-24 0OHM 1/8W
J607 653-0429-24 0OHM 1/8W
J608 653-0429-24 0OHM 1/8W
J609 653-0429-24 0OHM 1/8W
J611 653-0429-24 0OHM 1/8W
J612 653-0429-24 0OHM 1/8W
J613 653-0429-23 0OHM 1/16W
L301 653-0429-25 LK1608-4R7K-CT
L601 653-0429-26 TT-OL-5047-R2
L701 653-0429-27 EL0305RA-220J-FT
L702 653-0429-28 FCM1608K-301T03
P302 653-0429-29 SOCKET(TA HEAD)
P303 653-0429-30 SOCKET(TAPE)
P501 653-0429-31 16P SOCKET
P502 653-0429-32 RCA SOCKET
P701 653-0429-33 SOCKET(DISP)
