Clarion CZ101 Owner's Manual & Installation Manual

English
19
9. INSTALLATION / WIRE
CONNECTION GUIDE
1) Before Starting
1. This set is exclusively for use in cars with
a negative ground 12 V power supply.
2. Read these instructions carefully.
3. Be sure to disconnect the battery
“terminal” before starting. This is to
prevent short circuits during installation.
(Figure 1)
2) Package Contents
3) General Cautions
1. Do not open the case. There are no
user serviceable parts inside. If you
drop anything into the unit during
installation, consult your dealer or an
authorized Clarion service center.
2. Use a soft, dry cloth to clean the case.
Never use a rough cloth, thinner, benzine,
or alcohol etc. For tough dirt, apply a little
cold or warm water to a soft cloth and wipe
off the dirt gently.
CONTENTS
1) Before Starting ................................................................................. 19
2) Package Contents ............................................................................ 19
3) General Cautions ............................................................................. 19
4) Cautions on Installation .................................................................... 20
5) Installing the Source Unit ................................................................. 20
6) Removing the Source Unit ............................................................... 22
7) Wiring and Connections ................................................................... 23
8) Connecting the Accessories ............................................................. 24
Source unit ..................................................1
Front panel ..................................................1
Trim ring ......................................................1
Mounting bracket .........................................1
Screws M5x6 mm ........................................ 4
L-key ............................................................2
Wire connector ............................................1
Remote control unit (with battery)................1
Owner’s manual...........................................1
Warranty card ..............................................1
Special screw (Front panel lock) .................1
Car battery
Figure 1
