Clarion CZ109EL User Manual

English
6 CZ109EL
Note:
• Refer to the diagrams in “3. CONTROLS”
(page 4) when reading this chapter.
Basic Operations
CAUTION
Be sure to lower the volume before
switching off the unit power or car’s ignition
key. The unit remembers its last volume
setting.
Turning power on/off
1. Press the [SRC] button to turn on power.
2. Press and hold the [SRC] button (1 sec.) to
turn off power.
Selecting modes
1. Press the [SRC] button to change operation
mode.
2. Each time the [SRC] button is pressed, the
operation mode changes as follows:
Radio ➜ CD/MP3/WMA ➜ AUX ➜ Radio...
Adjusting the volume
1. Turn the [ROTARY] knob clockwise to
increase volume; turn counterclockwise to
decrease volume.
∗ Volume range is 0 (minimum) to 33 (maximum).
Switching the display
Press the [DISP] button to select desired
display.
Sound Adjustment
Sound effects and tone can be adjusted as
desired.
● Setting the Z-Enhancer Plus
This unit has 4 sound tone effects stored in
memory.
Select the effect you prefer.
∗ The factory default setting is “OFF”.
2-1. Select “Z-EHCR+”.
3-1. When you turn the [ROTARY] knob, the
tone effect changes as follows:
“OFF” ↔ “B-BOOST” ↔ “IMPACT” ↔
“EXCITE” ↔ “CUSTOM”
OFF : No sound effect
B-BOOST : Enhanced bass
IMPACT : Enhanced bass and treble
EXCITE : Enhanced bass, mid, and
treble
CUSTOM : User customized
When set to “B-BOOST/IMPACT/EXCITE”:
3-2. Press the [ ] button.
3-3. Turn the [ROTARY] knob to adjust the
setting (Setting range:
–3 to +3).
∗ The factory default setting is “0”.
3-4. Press the [ ] button to return to the
previous mode.
5. OPERATIONS
To change sound settings
1. Press the [SOUND] button to switch to the
sound adjustment display.
∗ The factory default sound setting is “Z-
EHCR+”.
2. Press [x] or [v] to select the sound
adjustment mode.
Each time [x] or [v] is pressed, the
sound adjustment mode changes as
follows:
“Z-EHCR+” ↔ “BASS” ↔ “TREBLE” ↔
“BALANCE” ↔ “FADER”
∗ When “ENT” is flashing in the display, press
the
[] button to adjust the setting value.
∗ The sound adjustment mode is displayed
for 2 seconds before showing the sound
setting.
3. Turn the [ROTARY] knob to adjust the
selected audio mode.
4. After completing settings, press the
[SOUND] button to return to the previous
mode.
01_CZ109EL_ENG.book Page 6 Thursday, May 21, 2009 5:05 PM
