Clarion CZ501 User Manual

English
31
SUB OUT 2
SUB OUT 1
SWC
MIC
7) Wiring and Connections
Rear audio
output terminal
Front audio
output terminal
Purple
Purple
4 Channel Amplier
Black
Black
Gray
White
White
Left
Left
Right
Right
Red
Red
Black
Black
SIRIUS
HD BUS
Antenna
Black
Black
Refer to next page
Steering wheel
control terminal
External Microphone
(RCB-199:Sold by separately)
Subwoofer output 1
Subwoofer output 2
HD RADIO
THD301
(Sold by separately.)
SIRIUS Connect™
Vehicle Tuner (SC-C1)
(Sold by separately)
CMB1525194A(Z501) manual.indb 31 2010-11-26 15:51:07
