Clarion CZ703E User Manual

English
18
CZ703E
7) Wiring and Connections
Refer to next page
MIC
SWC
4 Channel Amplier
2 Channel Amplier
Black
Black
Black
Black
Steering wheel
control terminal
USB Connector
External
microphone
(RCB-199:Sold separately)
White
Gray
Red
Left
Right
Front audio
output terminal
White
Black
Red
Left
Right
Rear audio
output terminal
Purple
Purple
Subwoofer output 1
Monaural output
Subwoofer output 2
Monaural output
Antenna
(Black)
DAB
DAB302E (sold separately)
(Black)
Refer to next page
MIC
SWC
4 Channel Amplier
2 Channel Amplier
Black
Black
Black
Black
Steering wheel
control terminal
USB Connector
External
microphone
(RCB-199:Sold separately)
White
Gray
Red
Left
Right
Mid audio
output terminal
White
Black
Red
Left
Right
High audio
output terminal
Purple
Purple
• Normal mode • 2 Way mode
Antenna
(Black)
DAB
DAB302E (sold separately)
(Black)
Rear audio output(Left)
Rear audio output(Right)
SUB OUT 1 REAR L
SUB OUT 2 REAR R
REAR L HIGH L
FRONT L MID L
REAR R HIGH R
DAB BUSANT
FRONT R MID R
ANT
SUB OUT 1 REAR L
SUB OUT 2 REAR R
REAR L HIGH L
FRONT L MID L
REAR R HIGH R
DAB BUS
FRONT R MID R
