Clarion CZ703E User Manual

English
19
CZ703E
• Connecting to the external amplier
External ampliers can be connected to the 4 and 2 channel RCA output
connections. Ensure that the connectors are not grounded or shorted to prevent
damage to the unit.
8) Connecting the accessories
For VW and Audi: Change wiring like above.
A
B
C
16
14
12
10
8
6
4
2
15
13
11
9
7
5
3
1
1
3
5
7
2
4
6
8
1
3
5
7
2
4
6
8
Rear right -
Front right -
Front left +
Rear left +
AMP Remote
ACC +
Ground
Rear right +
Front right +
Front left -
Rear left -
Phone Mute
Illumination
Battery +
/FUSE15A
Phone Mute / Brown Rear right (+) / Purple
Rear right (-) / Purple with black stripe
Front right (+) / Gray
Battery 12V(+) / Yellow
Front right (-) / Gray with black stripe
Remote On / Blue with white stripe
Illumination / Orange with white stripe
Front left (+) / White
Front left (-) / White with black stripe
ACC+ / Red Rear left (+) / Green
Ground / Black Rear left (-) / Green with black stripe
YellowYellow
Red Red
Function
Connector A Connector B
Location
Refer to the right
MIC
SWC
4 Channel Amplier
2 Channel Amplier
Black
Black
Black
Black
Steering wheel
control terminal
USB Connector
External
microphone
(RCB-199:Sold separately)
White
Gray
Red
Left
Right
Mid audio
output terminal
White
Black
Red
Left
Right
High audio
output terminal
• 3 Way mode
Purple
Purple
Antenna
(Black)
DAB
DAB302E (sold separately)
(Black)
Subwoofer output 1
Monaural output
Subwoofer output 2
Monaural output
SUB OUT 1 REAR L
SUB OUT 2 REAR R
REAR L HIGH L
FRONT L MID L
REAR R HIGH R
DAB BUSANT
FRONT R MID R
