Clarion DXZ785USB Service Manual

-16-
DXZ785USB/DXZ786USB
Switch PWB (B2) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C701 043-1741-90
180pF
D719 001-7088-90 HSMF-A355 R4 033-3941-15 1/10W 390k ohm
C702 042-0397-59
50V 1uF TAN
D720 001-7088-90 HSMF-A355 R700 033-1031-15 1/10W 10k ohm
C703 042-0397-59
50V 1uF TAN
IC701 052-7302-10
M30876MJB-713GP
R701 033-1031-15 1/10W 10k ohm
C704 042-0397-59
50V 1uF TAN
IC702 051-7507-08 SN74LV125APWR R702 033-1031-15 1/10W 10k ohm
C705 178-2242-78
50V 0.22uF
IR701 060-4017-90 RS-671 R703 033-1031-15 1/10W 10k ohm
C706 178-2242-78
50V 0.22uF
J701 074-2226-71 16P R704 033-1031-15 1/10W 10k ohm
C707 042-0423-97
16V 10uF TAN
L701 010-3407-59 5.6uH R705 119-1031-15 1/10W 10k ohm
C708 178-2242-78
50V 0.22uF
L702 010-3406-54 2.2uH R706 119-1041-15 1/10W 100k ohm
C709 178-2242-78
50V 0.22uF
L703 010-3112-91 GZ1608D15 R707 119-1031-15 1/10W 10k ohm
C710 178-2242-78
50V 0.22uF
L704 010-3112-91 GZ1608D15 R708 119-0000-05
1/10W 0 ohm JW
C711 043-1608-90 0.1uF L705 010-3112-91 GZ1608D15 R713 033-1031-15 1/10W 10k ohm
C711 046-1042-78 0.1uF L706 010-3112-91 GZ1608D15 R718 033-6811-15 1/10W 680 ohm
C712 043-1608-90 0.1uF L708 010-3112-91 GZ1608D15 R719 033-8211-15 1/10W 820 ohm
C712 046-1042-78 0.1uF L709 010-3112-91 GZ1608D15 R720 033-4711-15 1/10W 470 ohm
C713 043-1608-90 0.1uF L710 010-3112-91 GZ1608D15 R721 033-6811-15 1/10W 680 ohm
C713 046-1042-78 0.1uF P701 076-0647-00 16P R722 033-5611-15 1/10W 560 ohm
C714 043-1608-90 0.1uF Q709 125-2017-96 RN1426 R723 033-1521-15 1/10W 1.5k ohm
C714 046-1042-78 0.1uF Q710 125-2017-96 RN1426 R724 033-1021-15 1/10W 1k ohm
C715 043-1608-90 0.1uF Q711
191-1197-50 2SB1197K
R725 033-8211-15 1/10W 820 ohm
C715 046-1042-78 0.1uF Q711 190-1365-50 2SA1635 R726 033-1021-15 1/10W 1k ohm
C716 178-4742-78 0.47uF Q712
191-1197-50 2SB1197K
R727 033-1021-15 1/10W 1k ohm
C717 178-4742-78 0.47uF Q712 190-1365-50 2SA1635 R735 033-1521-15 1/10W 1.5k ohm
C718 043-1741-90
180pF
Q715 125-2017-96 RN1426 R736 033-1521-15 1/10W 1.5k ohm
C719 042-0423-97
16V 10uF TAN
Q716 125-2017-96 RN1426 R738 033-6811-15 1/10W 680 ohm
D701 001-2601-90 MA728 Q717
191-1197-50 2SB1197K
R739 033-8211-15 1/10W 820 ohm
D702 001-2601-90 MA728 Q717 190-1365-50 2SA1635 R740 033-8211-15 1/10W 820 ohm
D703 001-2601-90 MA728 Q718 125-2017-96 RN1426 R742 033-1031-15 1/10W 10k ohm
D704 001-2601-90 MA728 Q719 125-2017-96 RN1426 R743 033-2221-15 1/10W 2.2k ohm
D714 001-2601-90 MA728 R1 033-2241-15 1/10W 220k ohm R744 033-1031-15 1/10W 10k ohm
D717 001-7088-90 HSMF-A355 R2 033-1031-15 1/10W 10k ohm R745 033-2221-15 1/10W 2.2k ohm
D718 001-7088-90 HSMF-A355 R3 033-8241-15 1/10W 820k ohm R746 033-1031-15 1/10W 10k ohm
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R472 033-1021-15 1/16W 1k ohm R637 033-1031-15 1/16W 10k ohm R693 119-0000-05 1/10W 0 ohm JW
R473 033-3311-15 1/16W 330 ohm R638 033-1031-15 1/16W 10k ohm R697 033-4731-15 1/16W 47k ohm
R474 033-1021-15 1/16W 1k ohm R639 033-5621-15 1/16W 5.6k ohm R650 033-3321-15 1/16W 3.3k ohm
R475 033-3311-15 1/16W 330 ohm R640 033-4721-15 1/16W 4.7k ohm R651 033-1531-15 1/16W 15k ohm
R600 119-1011-15 1/10W 100 ohm R641 033-1031-15 1/16W 10k ohm R652 119-3321-15 1/10W 3.3k ohm
R601 033-1031-15 1/16W 10k ohm R642 033-1041-15 1/16W 100k ohm R653 119-0000-05 1/10W 0 ohm JW
R602 033-2231-15 1/16W 22k ohm R643 116-1801-15 1/4WS 18 ohm R654 032-0140-54
1/10W 22k ohm (F)
R603 119-3921-15 1/10W 3.9k ohm R644 119-1041-15 1/10W 100k ohm R655 033-1051-15 1/16W 1M ohm
R604 119-1031-15 1/10W 10k ohm R645 033-4731-15 1/16W 47k ohm R656 119-0000-05 1/10W 0 ohm JW
R605 116-4711-15 1/4WS 470 ohm R646 119-1031-15 1/10W 10k ohm R657 116-1591-15 1/4WS 1.5 ohm
R606 116-4711-15 1/4WS 470 ohm R647 116-1591-15 1/4WS 1.5 ohm R698 033-1041-15 1/16W 100k ohm
R607 033-1031-15 1/16W 10k ohm R648 032-0140-89
1/10W 47k ohm (F)
R801 119-0000-05 1/10W 0 ohm JW
R608 116-1811-15 1/4WS 180 ohm R649 116-1591-15 1/4WS 1.5 ohm R802 119-0000-05 1/10W 0 ohm JW
R609 033-2221-15 1/16W 2.2k ohm R658 033-2231-15 1/16W 22k ohm R803 119-0000-05 1/10W 0 ohm JW
R610 033-1031-15 1/16W 10k ohm R659 033-1031-15 1/16W 10k ohm R804 119-0000-05 1/10W 0 ohm JW
R611 033-1031-15 1/16W 10k ohm R660 116-1591-15 1/4WS 1.5 ohm R805 033-0000-05 0.5A 0 ohm
R612 033-1031-15 1/16W 10k ohm R661 116-6801-15 1/4WS 68 ohm R806 033-0000-05 0.5A 0 ohm
R613 119-1031-15 1/10W 10k ohm R662 033-1041-15 1/16W 100k ohm R807 033-0000-05 0.5A 0 ohm
(PE-3041B-A) R663 033-1031-15 1/16W 10k ohm R808 033-0000-05 0.5A 0 ohm
R614 119-1031-15 1/10W 10k ohm R664 119-4731-15 1/10W 47k ohm R809 033-5611-15 1/16W 560 ohm
R616 119-0000-05 1/10W 0 ohm JW R665 119-4731-15 1/10W 47k ohm R810 033-4711-15 1/16W 470 ohm
R617 119-2231-15 1/10W 22k ohm R666 116-1221-15 1/4WS 1.2k ohm R811 033-4711-15 1/16W 470 ohm
R620 119-1031-15 1/10W 10k ohm R667 032-0140-66
1/10W 220 ohm (F)
R813 033-5611-15 1/16W 560 ohm
(PE-3041K-A/B) R668 032-0140-67
1/10W 3.3k ohm (F)
R815 119-3311-15 1/10W 330 ohm
R622 119-1031-15 1/10W 10k ohm R670 033-4721-15 1/16W 4.7k ohm R816 119-3311-15 1/10W 330 ohm
R623 033-1811-15 1/16W 180 ohm R671 032-0140-56
1/10W 12k ohm (F)
R817 119-0000-05 1/10W 0 ohm JW
R624 033-1031-15 1/16W 10k ohm R672 119-4721-15 1/10W 4.7k ohm R818 119-5621-15 1/10W 5.6k ohm
R625 116-3911-15 1/4WS 390 ohm R673 033-1031-15 1/16W 10k ohm S601 013-6100-00 TACT SWITCH
R626 119-0000-05 1/10W 0 ohm JW R674 033-1031-15 1/16W 10k ohm S602 013-7106-00
DETECTOR SWITCH
R628 119-1011-15 1/10W 100 ohm R675 116-1221-15 1/4WS 1.2k ohm S603 013-7206-50
DETECTOR SWITCH
R629 033-1011-15 1/16W 100 ohm R676 119-0000-05 1/10W 0 ohm JW SUP1 060-8057-90 CSA20-141N-T
R630 119-1011-15 1/10W 100 ohm R677 119-4721-15 1/10W 4.7k ohm X301 061-3537-90 41.6MHz
R631 033-1011-15 1/16W 100 ohm R685 116-3311-15 1/4WS 330 ohm X601 060-1533-90 10MHz
R633 033-1021-15 1/16W 1k ohm R687 119-0000-05 1/10W 0 ohm JW X602 061-1056-00 32.768kHz
R634 033-1041-15 1/16W 100k ohm R688 033-1031-15 1/16W 10k ohm PWB 039-3049-01 PWB(WITHOUT
R635 119-4721-15 1/10W 4.7k ohm R690 119-4731-15 1/10W 47k ohm COMPONENT)
R636 033-1031-15 1/16W 10k ohm R691 119-1031-15 1/10W 10k ohm
