Clarion DXZ785USB Service Manual

-17-
D/D PWB (B3) section
MECH PWB (B4) section
DXZ785USB/DXZ786USB
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C502 042-1563-71 16V 100uF D507 001-0529-57 MA8120H R502 119-1031-15 1/10W 10k ohm
C503 043-1804-90 0.1uF D508 001-2635-90 D1FJ10 R506 119-1031-15 1/10W 10k ohm
C505 042-1563-71 16V 100uF FIL501 060-3116-55
CKD510JB1H102ST
R507 119-4701-15 1/10W 47 ohm
C506 043-1804-90 0.1uF FIL502 060-3116-55
CKD510JB1H102ST
R508 032-0140-90
1/10W 560 ohm F
C507 043-0510-51 25V 10uF FIL503 060-3115-52
CKD510JB1H102ST
R509 032-0164-50 1/10W 0.1 ohm F
C508 043-1800-90 1000pF IC501 051-3924-90 MD1424R R510 032-0164-50 1/10W 0.1 ohm F
C510 043-1800-90 1000pF J501 074-0898-16 16P R511 119-1001-15 1/10W 10 ohm
C511 043-1841-90 0.047uF L501 010-3600-90 2k ohm/100MHz R512 119-5631-15 1/10W 56k ohm
C512 043-1802-90 0.01uF L504 010-3041-90 10uH R513 119-1811-15 1/10W 180 ohm
C513 163-1073-35 16V 100uF L505 010-3108-53
330 ohm/100MHz
R514 119-1811-15 1/10W 180 ohm
C514 042-1697-00 10V 680uF L506 010-2275-50 33uH R516 032-0140-53
1/10W 2.2k ohm F
C517 043-1800-90 1000pF L507 010-2275-50 33uH R521 119-1051-15 1/10W 1M ohm
C521 043-1804-90 0.1uF Q501 125-2027-92
DTC124EUA-T106
R522 119-1031-15 1/10W 10k ohm
C523 163-2263-35 16V 22uF Q501 125-2041-93 RT1N241M R523 032-0140-15
1/10W 6.8k ohm F
C524 163-3363-45 16V 33uF Q502 190-1576-00 2SA1576A-T106 R527 119-1041-15 1/10W 100k ohm
C525 163-2263-35 16V 22uF Q502 125-3014-90 ISA1602A R529 119-3321-15 1/10W 3.3k ohm
C526 163-3363-45 16V 33uF Q503 192-2873-00 2SC2873 R530 119-3321-15 1/10W 3.3k ohm
D502 001-0608-90 D1FS4 Q504 125-2027-92
DTC124EUA-T106
T501 007-1180-00 SRW13EPC
D504 001-0507-90 DAP202K Q504 125-2041-93 RT1N241M PWB 039-3046-00 PWB(WITHOUT
D505 001-0529-57 MA8120H Q506 125-3010-90 KTA1666 COMPONENT)
D506 001-2635-90 D1FJ10 R501 119-1031-15 1/10W 10k ohm
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C2 043-1804-90 0.1uF C41 043-1804-90 0.1uF C90 043-1804-90 0.1uF
C3 042-0636-50 6.3V 100uF C42 043-1804-90 0.1uF C91 163-1063-35 16V 10uF
C4 043-1804-90 0.1uF C43 043-1804-90 0.1uF C92 163-1063-35 16V 10uF
C5 163-1073-35 16V 100uF C44 043-1607-90 0.01uF C93 043-1600-90 10pF
C6 163-1073-35 16V 100uF C45 043-1605-90 68pF C94 043-1600-90 10pF
C7 168-1052-78 1uF C46 043-1804-90 0.1uF C97 043-1804-90 0.1uF
C8 163-1063-35 16V 10uF C47 043-1610-90 0.015uF C98 043-1804-90 0.1uF
C9 168-1052-78 1uF C48 043-1804-90 0.1uF C99 043-1804-90 0.1uF
C10 042-0423-21 10V 22uF TAN C49 043-1607-90 0.01uF C100 043-1600-90 10pF
C11 042-0560-85 6.3V 100uF C50 043-1804-90 0.1uF C101 043-1600-90 10pF
C12 043-0552-90 6.3V 47uF C51 043-1804-90 0.1uF C102 043-1804-90 0.1uF
C13 043-1804-90 0.1uF C52 043-1609-90 1500pF C103 043-1607-90 0.01uF
C14 043-1804-90 0.1uF C53 043-1612-90 3300pF C104 043-1706-90 5pF
C15 168-1052-78 1uF C54 043-1607-90 0.01uF C105 043-1706-90 5pF
C16 168-1052-78 1uF C56 043-1804-90 0.1uF CCT1 050-0140-57
1/32W 10k ohm x4
C17 042-0423-21 10V 22uF TAN C57 043-1610-90 0.015uF CCT2 050-0140-54
1/32W 1k ohm x4
C20 043-1614-90 470pF C60 043-1604-90 47pF D1 001-0367-91 1SS226TE85L
C21 043-1841-90 0.047uF C61 043-1804-9 0 0.1uF D900 060-8078-00 EZAEG3A50AV
C22 043-1614-90 470pF C62 043-1804-90 0.1uF D901 060-8078-00 EZAEG3A50AV
C23 043-1841-90 0.047uF C63 043-1804-90 0.1uF D903 001-4316-16 LM3Z3V9T1G
C24 043-1713-90 12pF C64 043-1804-90 0.1uF IC1 051-6079-80 BA5830FM
C25 043-1713-90 12pF C65 043-0423-21 1 0V 22uF TAN IC2 052-3981-10
TMP92CD28AFG
C26 043-1804-90 0.1uF C66 043-1804-90 0.1uF -6UP2
C27 043-1611-90 2200pF C67 043-1804-90 0.1uF IC3 051-6733-20 TC94A70FG-010
C28 043-1804-90 0.1uF C70 168-1052-78 1uF IC5 051-6926-90 BD2051AFJ
C30 043-1617-90 6800pF C72 168-1052-78 1uF IC7 051-5418-08 S-80827CNMC
C31 043-1804-90 0.1uF C73 043-1804-90 0.1uF IC7 051-5418-18 BD4827G
C32 043-1804-90 0.1uF C74 043-1804-90 0.1uF IC8 051-6928-90 341S2094
C33 043-1613-90 0.033uF C78 043-1804-90 0.1uF IC997 051-7226-08 TC7SH00FU
C34 043-1804-90 0.1uF C79 043-1804-90 0.1uF IC998 051-3536-90 AP2121AK-
C35 043-1804-90 0.1uF C80 043-1804-90 0.1uF 1.5TRE1
C37 043-1804-90 0.1uF C81 043-1804-90 0.1uF IC999 051-3536-90 AP2121AK-
C38 043-0423-20 10V 10uF TAN C82 043-1804-90 0.1uF 1.5TRE1
C39 043-1804-90 0.1uF C83 043-1804-90 0.1uF J101 074-2220-79 29P
C40 043-1804-90 0.1uF C89 043-1613-90 0.033uF J201 074-2215-65 15P
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R747 033-1021-15 1/10W 1k ohm R762 033-1011-15 1/10W 100 ohm S709 013-7419-00 SWITCH
R748 033-2221-15 1/10W 2.2k ohm R763 033-1021-15 1/10W 1k ohm S710 013-7419-00 SWITCH
R751 033-1521-15 1/10W 1.5k ohm S701 013-6524-50 TACT SWITCH S711 013-7419-00 SWITCH
R754 033-8211-15 1/10W 820 ohm S702 013-6524-50 TACT SWITCH S715 013-6524-50 TACT SWITCH
R755 033-6811-15 1/10W 680 ohm S703 013-6524-50 TACT SWITCH S716 013-6524-50 TACT SWITCH
R756 033-8211-15 1/10W 820 ohm S704 013-6524-50 TACT SWITCH VR1 012-6004-59 47k ohm
R757 033-6811-15 1/10W 680 ohm S705 013-6524-50 TACT SWITCH X701 060-1533-90 10MHz
R760 033-3921-15 1/10W 3.9k ohm S706 013-6524-50 TACT SWITCH PWB 039-3230-00
PWB(WITHOUT
R761 033-1041-15 1/10W 100k ohm S707 013-6524-50 TACT SWITCH COMPONENT)
