Clarion M309 User Manual

Basic Operations
English
15 M309
3-2. When you select “ON”, press the [ ]
button, then press the [ ] or [ ] button
to select as following order.
LOW ↔ MID ↔ HIGH
Notes:
• Manufactured under license from BBE Sound,
Inc.
• Licensed by BBE Sound, Inc. under one or more
of the following US patents: 5510752, 5736897.
BBE and BBE symbol are registered trademarks
of BBE Sound, Inc.
● Adjusting the bass
2-1. Select “BASS”.
3-1. Press the [ ] or [ ] button to adjust the
gain from +7 to
–7.
∗ The factory default setting is “0”.
● Adjusting the treble
2-1. Select “TREBLE”.
3-1. Press the [ ] or [ ] button to adjust the
gain from +6 to
–6.
∗ The factory default setting is “0”.
● Adjusting the balance
2-1. Select “BALANCE”.
3-1. Press the [ ] or [ ] button to adjust the
balance of the right and left speakers.
∗ The factory default setting is “CENTER”
(center). (Adjustment range: RIGHT12 to
LEFT12 (right 12 to left 12))
● Adjusting the fader
2-1. Select “FADER”.
3-1. Press the [ ] or [ ] button to adjust the
balance of the rear and front speakers.
∗ The factory default setting is “CENTER”
(center). (Adjustment range: FRONT12 to
REAR12 (front 12 to rear 12))
● Adjusting the non-fader volume
Adjust volume output from the unit’s non-fader
output terminal.
2-1. Select “NO FADER”.
3-1. Press the [ ] or [ ] button to adjust the
volume.
∗ The factory default setting is “0”.
(Adjustment range: +6 to –6)
Note:
• During audio adjustment mode, if no operation is
performed for more than 10 seconds, this mode
can be cancelled and return to previous mode.
