NX603/FX503
15
English
●
Mount the GPS antenna.
Stick it surely on a flat plane of the passenger
-side dashboard where GPS signal
interruption is minimized.
●
Wire the GPS antenna cable.
Fasten the cable using the Cable holders.
GPS antenna
Cable holder
(Shows an example in case of the left-hand traffic.)
9. WIRE CONNECTION
Radio antenna jack
Microphone (sold
separately)
GPS antenna
jack (NX603
only)
Refer to the following
page.
Right
Left
Black
Black
Y
ellow
Red
White
Red
White
audio input
terminal
video output
terminal
SiriusXM-
Connect
V
ehicle T
uner
terminal (sold
separately)
Rear
audio
output
terminal
Android
smartphone
Android
smartphone
External
Amplifier
Rear Monitor
Steering
wheel remote
control
terminal (sold
separately)
Rear Vision
Camera
terminal
Purple
Right
Left
Gray
Red
White
Front
audio
output
terminal
Subwoofer
output
terminal
(MONO 2ch)
Right
Left
Y
ellow
White
Right
Left
video input
terminal
Gray
iPod
®
/iPhone
HDMI
cable
(sold separately)
HDMI/MHL
conversion adapter
HDMI/MHL
conversion cable
or
Black
Red
USB terminal
Connection cable
(CCA-750)
15
17
