929-0383-80
- M6 -
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
to A7
D2
D1
to C2
to A1
D3
to D2
to D1
A3
A5
A6
A2
A1
A4
A7
to D3
C1
to A4
to A5
C4
C3
to A3
C2
to A2
to A6
to C1
to C4
to C3
to B1
to B2
B1
B2
1
*24
13
20
*28
23
21
*28
*25
14
11
15
35
31
*32
*30
*31
27
22
27
8
26
18
3
4
17
26
*29
27
*29
5
2
19
6
33
34
35
7
23
16
23
12
10
33
34
27
27
9
27
27
to E1
E1
EXPLODED VIEW/PARTS LIST
Main section
* Do not reuse the following parts.
(No.24,25,28,29,30,31,32)
1 966-1865-20 LOWER UNIT ASSY 1
2 966-0667-21 DISC STP-ASSY L 1
3 966-1806-20 DH-SEL-ASSY S 1
4 966-1807-20 DH-SEL-ASSY R 1
5 966-0670-22 DS-SP-ASSY L 1
6 966-0671-23 DS-SP-ASSY R 1
7 966-0672-21 REAR-P-ASSY 1
8 966-1753-21 N-DRIVE-CH UNIT 1
9 966-1764-21 UPPRR UNIT ASSY 1
10 HBS-566-300 DISCHOLDER UNIT 1
11 966-0709-21 SLIDE-P-ASSY R 1
12 966-0668-24 DH-SEL-ASSY S 1
13 HBS-582-100 CD-PWB-ASSY 1
14 620-1640-20 SW-H-PLATE 1
15 620-1778-20 GAP PLATE F 1
16 620-1662-21 GAP PLATE F L 1
17 620-1685-21 DS-PLATE L 1
18 620-1686-20 DS-PLATE R 1
19 621-1634-23 DISC STOPPER R 1
20 621-1636-24 SW LINK 1
21 621-1765-20 UD-GEAR-D 1
22 621-1715-20 FPC-STOPPER 1
23 716-1850-01 SCREW (M2.0x2.0) 4
24 716-1850-02 SCREW (M2.0x2.0) 1
25 716-1851-02 SCREW (M2.0x3.0) 1
26 716-3450-00 SCREW (M1.7x2.0) 2
27 716-3451-01 SCREW (M1.7x2.5) 8
28 746-0761-00 WASHER 2
29 744-0045-01 C-RING 1
30 347-7271-00 FPC SHEET 1
31 347-7275-00 PROTECT SHEET 1
32 347-7276-00 FPC-SHEET C 1
33 800-4921-60 VINYL-COAT WIRE 1
34 802-4921-60 VINYL-COAT WIRE 1
35 345-5824-00 RUBBER PART 1
36 621-1763-20 LOADING GUIDE B 1
37 716-1859-01 SCREW (M1.7x2.0) 1
