Clarion PN-2940S-C User Manual

PN-2940S-A,
S-B,C,D,E,F
- 7 -
Switch PWB(B2) section
C51 117-1021-15 1/8W 1k ohm
C52 178-1052-78 1uF
C401 168-1042-78 16V 0.1uF
C403 166-2211-50 220pF CH
C404 168-1042-78 16V 0.1uF
C406 166-2211-50 220pF CH
D401 001-7093-92 RFA1112H(ORG)
D402 001-7093-92 RFA1112H(ORG)
D403 001-7093-92 RFA1112H(ORG)
D404 001-7093-92 RFA1112H(ORG)
D405 001-7093-92 RFA1112H(ORG)
D406 001-7093-92 RFA1112H(ORG)
D407 001-7107-91 LS E6SF-AABA-1-
1(RED)
D408 001-7107-91 LS E6SF-AABA-1-
1(RED)
D409 001-7107-91 LS E6SF-AABA-1-
1(RED)
D410 001-7107-91 LS E6SF-AABA-1-
1(RED)
D411 001-7107-91 LS E6SF-AABA-1-
1(RED)
D412 001-7107-91 LS E6SF-AABA-1-
1(RED)
D413 001-7093-92 RFA1112H(ORG)
D414 001-7093-92 RFA1112H(ORG)
D415 001-7093-92 RFA1112H(ORG)
D416 001-7093-92 RFA1112H(ORG)
D417 001-7093-92 RFA1112H(ORG)
D418 001-7093-92 RFA1112H(ORG)
D419 001-7093-92 RFA1112H(ORG)
D420 001-7093-92 RFA1112H(ORG)
D423 001-7093-92 RFA1112H(ORG)
D424 001-7093-92 RFA1112H(ORG)
D425 001-7093-92 RFA1112H(ORG)
D426 001-7093-92 RFA1112H(ORG)
D427 001-7093-92 RFA1112H(ORG)
D486 001-7093-92 RFA1112H(ORG)
D487 001-7093-92 RFA1112H(ORG)
D491 001-7093-92 RFA1112H(ORG)
D492 001-7093-92 RFA1112H(ORG)
IC1 051-6088-90 BU2099FV-E2
IC2 051-6088-90 BU2099FV-E2
J1 074-1189-90 40P
Q10 190-1586-50 2SA1586 Y,G
R401 117-1221-15 1/8W 1.2k ohm
R402 117-1221-15 1/8W 1.2k ohm
R403 117-1221-15 1/8W 1.2k ohm
R404 117-1021-15 1/8W 1k ohm
R405 117-1021-15 1/8W 1k ohm
R406 117-1221-15 1/8W 1.2k ohm
R407 117-3311-15 1/8W 330 ohm
R408 117-3311-15 1/8W 330 ohm
R409 117-3311-15 1/8W 330 ohm
R410 117-3311-15 1/8W 330 ohm
R411 117-3911-15 1/8W 390 ohm
R412 117-3311-15 1/8W 330 ohm
R413 117-2221-15 1/8W 2.2k ohm
R414 117-2221-15 1/8W 2.2k ohm
R415 117-1521-15 1/8W 1.5k ohm
R416 117-2221-15 1/8W 2.2k ohm
R417 117-2221-15 1/8W 2.2k ohm
R418 117-1521-15 1/8W 1.5k ohm
R419 117-2221-15 1/8W 2.2k ohm
R420 117-1821-15 1/8W 1.8k ohm
R423 117-1021-15 1/8W 1k ohm
R424 117-1021-15 1/8W 1k ohm
R425 117-1021-15 1/8W 1k ohm
R426 117-8211-15 1/8W 820 ohm
R427 117-1221-15 1/8W 1.2k ohm
R428 119-1031-15 1/10W 10k ohm
R429 119-1021-15 1/10W 1k ohm
R430 119-1021-15 1/10W 1k ohm
R431 119-1021-15 1/10W 1k ohm
R432 119-1021-15 1/10W 1k ohm
R433 119-1021-15 1/10W 1k ohm
R434 119-1021-15 1/10W 1k ohm
R435 119-1021-15 1/10W 1k ohm
R486 117-2221-15 1/8W 2.2k ohm
R487 117-2221-15 1/8W 2.2k ohm
R491 117-1521-15 1/8W 1.5k ohm
R492 117-1221-15 1/8W 1.2k ohm
S401 013-6301-50 SKQGAB
S402 013-6301-50 SKQGAB
S403 013-6301-50 SKQGAB
S404 013-6301-50 SKQGAB
S405 013-6301-50 SKQGAB
S406 013-6301-50 SKQGAB
S407 013-6301-50 SKQGAB
S408 013-6301-50 SKQGAB
S409 013-6301-50 SKQGAB
S410 013-6301-50 SKQGAB
S411 013-6301-50 SKQGAB
S412 013-6301-50 SKQGAB
S413 013-6301-50 SKQGAB
S414 013-6301-50 SKQGAB
S415 013-6301-50 SKQGAB
S416 013-6301-50 SKQGAB
S417 013-6301-50 SKQGAB
S418 013-6301-50 SKQGAB
S419 013-6301-50 SKQGAB
TM1 073-0778-90 TERMINAL
VR401 016-7000-00 ROTARY ENCODER
PWB 039-3065-00 PWB(WITHOUT
COMPONENT)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
