Clarion PS-2808K-A User Manual

PS-2808K-A
- 8 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D505 001-0516-90 MA111
D506 001-2403-90 M1F60
D507 001-4301-25 HZU4.7B1
D508 001-0466-90 S5688B
D509 001-0504-36 S5689B
D701 001-0424-31 MA4180
D702 001-0424-31 MA4180
D703 001-0424-31 MA4180
D711 001-0466-90 S5688B
D712 001-0466-90 S5688B
D731 001-0466-90 S5688B
D761 001-0504-39 HZS7B2L
D771 001-0347-43 MA40482LTA
D772 001-0347-25 MA4047LTA
D801 001-0592-00 RM4Z
D851 001-4301-68 HZU18B1
IC121 051-6201-90 LC72146M
IC241 051-3367-90 NJU7780U1-33-TE2
IC272 051-3334-00 NJM2396F0
IC301 051-5042-91 CL7639V11
IC351 051-3034-90 NJM4558V
IC391 051-2040-00 TA8276H
IC501 052-3196-21 M30622MGP-E22GP
IC502 051-0869-58 NJM2103M
IC503 051-9400-29 BR93L46F-W
IC504 051-6600-58 HA12187FP
IC741 051-3369-00 NJM2388F8
J241 074-1237-69 19PIN
J701 074-1194-00 13PIN
J721 074-1302-08 8PIN
J801 074-4007-20 20PIN
L101 010-2003-04 30uH
L102 010-6009-76 22uH J
L103 010-6009-76 22uH J
L121 010-6009-76 22uH J
L501 010-6009-76 22uH J
L502 010-6009-76 22uH J
L801 010-8026-00 210uH
P501 076-0662-74 24P
P503 076-0717-09 9P
Q121 190-1298-00 2SA1298
Q122 190-1298-00 2SA1298
Q123 190-1298-00 2SA1298
Q241 125-0021-91 DTA114EUA
Q242 125-2027-91 DTC114EUA
Q243 193-0601-00 2SD601A
Q244 192-4116-00 2SC4116
Q245 125-2027-91 DTC114EUA
Q246 125-0021-91 DTA114EUA
Q247 125-2027-91 DTC114EUA
Q248 198-3018-00 2SK3018
Q249 198-3018-00 2SK3018
Q391 125-2027-91 DTC114EUA
Q392 192-4116-00 2SC4116
Q502 190-1736-00 2SA1736
Q503 192-4116-00 2SC4116
Q504 192-4116-00 2SC4116
Q505 192-4116-00 2SC4116
Q506 193-2118-50 2SD2118F5 R,S
Q701 192-4116-00 2SC4116
Q711 190-1736-00 2SA1736
Q712 192-4116-00 2SC4116
Q761 193-1664-00 2SD1664 P,Q,R
Q762 125-0021-91 DTA114EUA
Q763 125-2027-91 DTC114EUA
Q771 193-2118-00 2SD2118F5 Q,R,S
Q773 192-4116-00 2SC4116
Q775 192-4116-00 2SC4116
Q776 125-0021-91 DTA114EUA
Q777 125-2027-91 DTC114EUA
Q791 192-4116-00 2SC4116
Q792 192-4116-00 2SC4116
Q821 190-1736-00 2SA1736
Q822 192-4116-00 2SC4116
R101 119-0000-05 1/10W 0 ohm JW
R102 119-0000-05 1/10W 0 ohm JW
R103 119-1041-15 1/10W 100k ohm
R104 119-2221-15 1/10W 2.2k ohm
R105 119-3911-15 1/10W 390 ohm
R106 119-2221-15 1/10W 2.2k ohm
R107 116-1001-15 1/4W 10 ohm
R108 119-2231-15 1/10W 22k ohm
R109 119-5121-15 1/10W 5.1k ohm
R111 166-8201-50 82pF CH
R121 119-0000-05 1/10W 0 ohm JW
R122 119-3321-15 1/10W 3.3k ohm
R123 119-4721-15 1/10W 4.7k ohm
R124 119-2221-15 1/10W 2.2k ohm
R125 119-1021-15 1/10W 1k ohm
R127 119-5631-15 1/10W 56k ohm
R128 119-4731-15 1/10W 47k ohm
R130 119-2221-15 1/10W 2.2k ohm
R131 119-1031-15 1/10W 10k ohm
R132 119-1031-15 1/10W 10k ohm
R133 119-2221-15 1/10W 2.2k ohm
R134 119-2221-15 1/10W 2.2k ohm
R135 119-1031-15 1/10W 10k ohm
R242 119-4731-15 1/10W 47k ohm
R243 119-1021-15 1/10W 1k ohm
R245 119-3331-15 1/10W 33k ohm
R246 119-4731-15 1/10W 47k ohm
R248 119-1041-15 1/10W 100k ohm
R250 119-3331-15 1/10W 33k ohm
R253 119-4731-15 1/10W 47k ohm
R255 119-3331-15 1/10W 33k ohm
R256 119-0000-05 1/10W 0 ohm JW
R258 119-4731-15 1/10W 47k ohm
R271 119-4731-15 1/10W 47k ohm
R273 119-0000-05 1/10W 0 ohm JW
R301 119-1021-15 1/10W 1k ohm
R302 119-1021-15 1/10W 1k ohm
R305 119-1021-15 1/10W 1k ohm
R306 119-1021-15 1/10W 1k ohm
R309 119-1021-15 1/10W 1k ohm
R310 119-1021-15 1/10W 1k ohm
R311 119-5631-15 1/10W 56k ohm
R312 119-5631-15 1/10W 56k ohm
R313 119-5631-15 1/10W 56k ohm
R314 119-5631-15 1/10W 56k ohm
R319 119-1031-15 1/10W 10k ohm
R320 119-1221-15 1/10W 1.2k ohm
R321 119-1031-15 1/10W 10k ohm
R322 119-1221-15 1/10W 1.2k ohm
R323 119-0000-05 1/10W 0 ohm JW
R324 119-0000-05 1/10W 0 ohm JW
R325 119-0000-05 1/10W 0 ohm JW
R326 119-0000-05 1/10W 0 ohm JW
R351 119-8211-15 1/10W 820 ohm
R352 119-1021-15 1/10W 1k ohm
R353 032-0140-50 1/10W 10k ohm F
R354 032-0140-50 1/10W 10k ohm F
R355 032-0140-50 1/10W 10k ohm F
R356 032-0140-50 1/10W 10k ohm F
R357 032-0140-50 1/10W 10k ohm F
R358 032-0140-50 1/10W 10k ohm F
R359 032-0140-50 1/10W 10k ohm F
R360 032-0140-50 1/10W 10k ohm F
R391 119-5631-15 1/10W 56k ohm
R392 119-1221-15 1/10W 1.2k ohm
R393 119-2221-15 1/10W 2.2k ohm
R394 119-2221-15 1/10W 2.2k ohm
R395 119-2221-15 1/10W 2.2k ohm
R396 119-2221-15 1/10W 2.2k ohm
R397 119-1031-15 1/10W 10k ohm
R398 119-4731-15 1/10W 47k ohm
R399 119-4731-15 1/10W 47k ohm
R400 119-1031-15 1/10W 10k ohm
R502 119-4721-15 1/10W 4.7k ohm
R503 119-4721-15 1/10W 4.7k ohm
R504 119-4721-15 1/10W 4.7k ohm
R510 119-4721-15 1/10W 4.7k ohm
R511 119-4721-15 1/10W 4.7k ohm
R512 119-4721-15 1/10W 4.7k ohm
R513 119-4721-15 1/10W 4.7k ohm
R514 119-1021-15 1/10W 1k ohm
R515 119-1041-15 1/10W 100k ohm
R516 119-1041-15 1/10W 100k ohm
R517 116-1001-15 1/4W 10 ohm
R520 119-4731-15 1/10W 47k ohm
R521 119-4731-15 1/10W 47k ohm
R522 119-4731-15 1/10W 47k ohm
R527 119-4721-15 1/10W 4.7k ohm
R528 032-0140-66 1/10W 220 ohm F
R529 119-1031-15 1/10W 10k ohm
R530 119-1041-15 1/10W 100k ohm
R531 119-1031-15 1/10W 10k ohm
R532 119-4721-15 1/10W 4.7k ohm
R533 119-4721-15 1/10W 4.7k ohm
R534 119-1021-15 1/10W 1k ohm
R535 119-1031-15 1/10W 10k ohm
R536 119-2221-15 1/10W 2.2k ohm
R537 119-1031-15 1/10W 10k ohm
R538 119-1031-15 1/10W 10k ohm
R539 119-1031-15 1/10W 10k ohm
R540 119-4731-15 1/10W 47k ohm
R541 119-5621-15 1/10W 5.6k ohm
R542 119-2231-15 1/10W 22k ohm
R544 119-4731-15 1/10W 47k ohm
R545 119-6831-15 1/10W 68k ohm
R546 119-1021-15 1/10W 1k ohm
R547 119-1021-15 1/10W 1k ohm
R548 119-1031-15 1/10W 10k ohm
R549 119-3341-15 1/10W 330k ohm
R550 032-0140-22 1/10W 68k ohm F
R551 032-0140-00 1/10W 56k ohm F
R552 117-6821-15 1/8W 6.8k ohm
R553 119-4731-15 1/10W 47k ohm
R554 119-4731-15 1/10W 47k ohm
R555 119-5621-15 1/10W 5.6k ohm
R556 119-1021-15 1/10W 1k ohm
R557 119-2231-15 1/10W 22k ohm
R558 119-2231-15 1/10W 22k ohm
R559 119-1021-15 1/10W 1k ohm
R560 119-1021-15 1/10W 1k ohm
R561 119-1021-15 1/10W 1k ohm
R562 119-1021-15 1/10W 1k ohm
R563 119-0000-05 1/10W 0 ohm JW
R564 119-1021-15 1/10W 1k ohm
R566 119-1021-15 1/10W 1k ohm
R568 119-4731-15 1/10W 47k ohm
R569 119-4731-15 1/10W 47k ohm
R572 119-4731-15 1/10W 47k ohm
R573 119-4731-15 1/10W 47k ohm
R701 116-1211-15 1/4W 120 ohm
R702 116-6801-15 1/4W 68 ohm
R703 119-2231-15 1/10W 22k ohm
R704 119-2231-15 1/10W 22k ohm
R711 116-2221-15 1/4W 2.2k ohm
R712 117-1031-15 1/8W 10k ohm
R713 116-2221-15 1/4W 2.2k ohm
R714 119-1031-15 1/10W 10k ohm
R715 119-3321-15 1/10W 3.3k ohm
R726 119-1021-15 1/10W 1k ohm
R731 116-5621-15 1/4W 5.6k ohm
R732 116-4721-15 1/4W 4.7k ohm
R761 032-0092-56 1/8W 22k ohm F
R762 119-1541-15 1/10W 150k ohm
R763 032-0092-51 1/8W 1k ohm F
R764 119-1221-15 1/10W 1.2k ohm
R772 119-2231-15 1/10W 22k ohm
R773 116-1021-15 1/4W 1k ohm
R774 119-2231-15 1/10W 22k ohm
