Clarion PS-2808K-A User Manual

PS-2808K-A
- 7 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ELECTRICAL PARTS LIST
Switch PWB section (B1)
C100 168-1042-78 16V 0.1uF
C101 168-1042-78 16V 0.1uF
C102 168-1042-78 16V 0.1uF
C103 168-1042-78 16V 0.1uF
C104 168-1042-78 16V 0.1uF
C105 178-1052-78 1uF
D100 001-7048-91 RFR1112H-22 C,D
RED
D101 001-7048-91 RFR1112H-22 C,D
RED
D102 001-7048-91 RFR1112H-22 C,D
RED
D103 001-7048-91 RFR1112H-22 C,D
RED
D104 001-7087-90 RBR1112H C,D,E
RED
D105 001-7048-91 RFR1112H-22 C,D
RED
D106 001-7048-91 RFR1112H-22 C,D
RED
D107 001-7048-91 RFR1112H-22 C,D
RED
D108 001-7048-91 RFR1112H-22 C,D
RED
D113 001-0516-90 MA111
D114 001-0516-90 MA111
D115 001-0516-90 MA111
D116 001-0516-90 MA111
IC100 051-6084-00 NJU6625FG1-03
J100 074-3013-74 24P
L100 010-3406-66 22uH J
PL100 017-0420-43 14V 40mA RED
PL101 017-0420-43 14V 40mA RED
PL102 017-0420-43 14V 40mA RED
PL104 017-0420-43 14V 40mA RED
PL105 017-0420-43 14V 40mA RED
PL106 017-0420-43 14V 40mA RED
PL107 017-0420-43 14V 40mA RED
PL108 017-0420-43 14V 40mA RED
PL109 017-0420-43 14V 40mA RED
PL110 017-0420-43 14V 40mA RED
PL111 017-0420-43 14V 40mA RED
R100 119-5611-15 1/10W 560 ohm
R101 119-4711-15 1/10W 470 ohm
R102 119-4711-15 1/10W 470 ohm
R103 119-5611-15 1/10W 560 ohm
R104 119-4711-15 1/10W 470 ohm
R105 119-4711-15 1/10W 470 ohm
R106 119-5611-15 1/10W 560 ohm
R107 119-4711-15 1/10W 470 ohm
R108 119-4711-15 1/10W 470 ohm
R109 119-5611-15 1/10W 560 ohm
R110 119-4711-15 1/10W 470 ohm
R111 119-4711-15 1/10W 470 ohm
R112 119-8211-15 1/10W 820 ohm
R113 119-8211-15 1/10W 820 ohm
R114 119-7511-15 1/10W 750 ohm
R116 119-0000-05 1/10W 0 ohm JW
R117 119-0000-05 1/10W 0 ohm JW
R121 119-4341-15 1/10W 430k ohm
R122 119-0000-05 1/10W 0 ohm JW
R123 119-0000-05 1/10W 0 ohm JW
R125 119-0000-05 1/10W 0 ohm JW
R126 119-0000-05 1/10W 0 ohm JW
R128 119-1021-15 1/10W 1k ohm
R129 119-1021-15 1/10W 1k ohm
R131 119-0000-05 1/10W 0 ohm JW
R132 119-0000-05 1/10W 0 ohm JW
R200 119-1841-15 1/10W 180k ohm
R201 119-1841-15 1/10W 180k ohm
R202 119-1841-15 1/10W 180k ohm
R203 119-1841-15 1/10W 180k ohm
TH100 002-0306-90 SC20-3J153
TM100 073-0778-90 TERMINAL
VR100 016-0014-12 VR W/SHAFT
VR101 016-0014-12 VR W/SHAFT
PWB 039-2920-00 PWB(WITHOUT
COMPONENT)
Main PWB section (B2)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ANT101 092-0702-00 ANT-RECEPT
BL101 941-0221-70 TUNER PACK
C103 168-2232-55 0.022uF K
C104 188-1073-28 10V 100uF
C105 168-1042-78 16V 0.1uF
C106 168-1042-78 16V 0.1uF
C107 188-1073-28 10V 100uF
C108 168-1042-78 16V 0.1uF
C109 168-2232-55 0.022uF K
C111 168-2232-55 0.022uF K
C112 168-4745-79 0.47uF Z
C113 168-5632-78 16V 0.056uF
C114 168-5632-78 16V 0.056uF
C121 166-1501-50 15pF CH
C122 188-4763-38 16V 47uF
C123 168-1022-55 1000pF K
C124 042-1458-90 50V 1uF LN
C125 166-1501-50 15pF CH
C126 166-1011-50 100pF CH
C127 166-1011-50 100pF CH
C128 166-1011-50 100pF CH
C129 166-1011-50 100pF CH
C130 168-2232-55 0.022uF K
C131 188-4763-38 16V 47uF
C132 166-1811-50 180pF CH
C133 168-1042-78 16V 0.1uF
C160 168-1042-78 16V 0.1uF
C212 188-4763-38 16V 47uF
C222 168-1042-78 16V 0.1uF
C241 168-2232-55 0.022uF K
C243 188-4763-38 16V 47uF
C244 168-1042-78 16V 0.1uF
C245 168-1042-78 16V 0.1uF
C274 189-2273-29 10V 220uF
C276 043-0328-90 0.1uF
C301 178-1052-78 1uF
C302 178-1052-78 1uF
C305 178-1052-78 1uF
C306 178-1052-78 1uF
C309 168-2232-55 0.022uF K
C310 168-2232-55 0.022uF K
C311 188-2253-68 50V 2.2uF
C312 188-2253-68 50V 2.2uF
C313 188-2253-68 50V 2.2uF
C314 188-2253-68 50V 2.2uF
C318 168-1522-55 1500pF K
C319 168-1522-55 1500pF K
C322 188-1063-38 16V 10uF
C323 188-1063-38 16V 10uF
C324 188-1073-28 10V 100uF
C325 168-1042-78 16V 0.1uF
C326 188-1053-68 50V 1uF
C327 188-1053-68 50V 1uF
C328 188-2253-68 50V 2.2uF
C329 188-2253-68 50V 2.2uF
C330 168-2222-55 2200pF K
C331 168-2222-55 2200pF K
C332 178-3342-78 0.33uF
C333 178-3342-78 0.33uF
C334 166-4711-50 470pF CH
C335 166-4711-50 470pF CH
C346 188-1073-28 10V 100uF
C352 168-1042-78 16V 0.1uF
C353 042-1562-15 10V 220uF
C354 166-2201-50 22pF CH
C355 166-2201-50 22pF CH
C356 166-1007-50 10pF CH
C357 166-1007-50 10pF CH
C358 188-1063-38 16V 10uF
C359 188-1063-38 16V 10uF
C360 188-1063-38 16V 10uF
C361 188-1063-38 16V 10uF
C391 168-1042-78 16V 0.1uF
C392 168-1042-78 16V 0.1uF
C393 168-1042-78 16V 0.1uF
C394 168-1042-78 16V 0.1uF
C395 168-1032-55 0.01uF K
C396 163-1053-65 50V 1uF
C397 042-1624-00 4700 16V
C398 163-1063-35 16V 10uF
C399 163-1053-65 50V 1uF
C501 168-1042-78 16V 0.1uF
C502 188-4763-18 6.3V 47uF
C503 168-1032-55 0.01uF K
C504 168-1032-55 0.01uF K
C505 168-1032-55 0.01uF K
C506 168-1042-78 16V 0.1uF
C507 188-1053-68 50V 1uF
C509 168-1022-55 1000pF K
C510 168-1022-55 1000pF K
C511 168-1042-78 16V 0.1uF
C512 168-1032-55 0.01uF K
C513 189-1073-29 10V 100uF
C514 168-1042-78 16V 0.1uF
C515 166-1011-50 100pF CH
C516 188-1063-38 16V 10uF
C517 042-0559-00 0.1F 5.5V
C722 168-1042-78 16V 0.1uF
C731 172-1041-15 0.1uF
C732 188-1053-68 50V 1uF
C741 043-0328-90 0.1uF
C744 188-1073-28 10V 100uF
C761 188-1063-38 16V 10uF
C762 188-1063-38 16V 10uF
C771 188-1073-28 10V 100uF
C772 188-1063-38 16V 10uF
C791 188-4756-58 35V 4.7uF
C792 168-1042-78 16V 0.1uF
C811 172-1041-15 0.1uF
C821 188-1063-38 16V 10uF
CCT501 050-0140-54 1/32W 1k ohm x4J
CCT504 050-0140-54 1/32W 1k ohm x4J
CCT505 050-0140-54 1/32W 1k ohm x4J
D391 001-0516-90 MA111
