English
VX400/VZ400 45
English
Owner’s Manual
10. SPECIFICATIONS
FM Tuner
Frequency Range: 87.9 MHz to 107.9 MHz
Usable Sensitivity: 8 dBμV
50dB Quieting Sensitivity: 14 dBμV
Alternate Channel Selectivity: 70 dB
Stereo Separation: 25 dB (1 kHz)
Frequency Response: 30 Hz to 15kHz
AM Tuner
Frequency Range: 530 kHz to 1710 kHz
Usable Sensitivity: 28 dBμV
DVD Player System
Digital Versatile Disc System with CDDA
capable
Usable discs:
DVD video disc, Compact disc
Frequency Response: 20 Hz to 20 kHz
Sound/Noise Ratio: 95 dbA (1W Ref)
Dynamic Range: 95 dB (1 kHz)
Distortion: 0.05%
Video system: NTSC
Audio/Video Input
Audio input voltage: 300 μVrμs (low)
Audio input voltage: 600 μVrμs (med)
Audio input voltage: 950 μVrμs (high)
Video input voltage: 1.0Vp-p @75
Audio/Video output
Audio output impedance: 10k
Video output voltage: 1.0Vp-p @75
LCD Monitor
VX400 Screen Size: 6.5” wide type
Pixels: 280,800
Resolution: 1200 x 234 (RGB)
VZ400 Screen Size: 7” wide type
Pixels: 336,960
Resolution: 1440x234 (RGB)4 (RGB)
General
Power source voltage:
14.4 V DC (10.8 to 15.6 V allowable)
Ground: Negative
Current consumption:
4.0 A @1 W (57.6W @1W)
Auto Antenna Rated Current: 500 mA less
VX400 dimensions:
7” (178mm) width, 3-15/16” (100mm) height,
7” (179mm) depth
VX400 weight: 3.5 kg
VZ400 dimensions:
7” (178mm) width, 2” (50 mm) height,
7.5” (191.5mm) depth
VZ400 weight: 3.5 kg
Remote Control dimensions:
2-1/8” (54mm) width, 9/16” (14mm) height
4-13/16” (122 mm) depth
Remote Control weight:
50 grams (including battery)
Note:
•
Specifications comply with JEITA
Standards
.
•
Specifications and design are subject
to change without notice for further
improvement.
Power Output:
18W RMS x 4 Channels at 4
and 1% THD+N
Signal to Noise Ratio:
85 dBA (reference: 1W into 4
)
