12 XN3210/XN3410
English
Owner’s Manual
Bridged Left Subwoofer
Bridged Right Subwoofer
OR
4 Ω BRIDGED
FUSE
+ CH1 –
GND REM +12V
30A 30A
+ CH2 –
4 Ω BRIDGED
+ CH3 – + CH4 –
Bridged CH1/CH2
Speaker System
Bridged CH3/CH4
Speaker System
Fig. 7
2-Channel High Power System (Satellite or Subwoofer)
The XN3410 can be set up as a 2-channel high power amplifier to drive a pair of
satellites (or subwoofers)
